| # | Part no | Qty | Description |
| 1 | 3803667 | 1 | Cylinder head |
| Including valves., (3586779) | |||
| 2 | 3165130 | 1 | Bearing housing, front |
| Included in overhaul kit 3165309. | |||
| 2 | 3165133 | 5 | Bearing housing, middle |
| Included in overhaul kit 3165309. | |||
| 2 | 3165136 | 1 | Bearing housing, rear |
| Included in overhaul kit 3165309. | |||
| 3 | 950542 | 14 | Pin |
| 4 | 8170626 | 7 | Flange screw |
| 5 | 1547889 | 14 | Flange screw |
| L=127mm | |||
| 6 | 1547888 | 1 | Flange screw |
| L=106mm | |||
| 7 | 1677283 | 6 | Flange screw |
| L=70mm | |||
| 8 | 1546437 | 24 | Valve guide |
| SN-303403 | |||
| 8 | 20817645 | 24 | Valve guide |
| SN303404-, (3165303) | |||
| 9 | 3183227 | 12 | Valve seat, intake |
| Std SN-303403 | |||
| 9 | 3183228 | 12 | Valve seat |
| O.S=0,20mm | |||
| 9 | 20459329 | 12 | Valve seat, intake |
| Std SN303404- | |||
| 9 | 20459332 | 12 | Valve seat |
| O.S=0,20mm | |||
| 10 | 3165369 | 12 | Valve seat, exhaust |
| Std SN-303403 | |||
| 10 | 3165397 | 12 | Valve seat |
| O.S=0,20mm | |||
| 10 | 3169366 | 12 | Valve seat, exhaust |
| Std SN303404- | |||
| 10 | 20411979 | 12 | Valve seat |
| O.S=0,20mm | |||
| 11 | 85104134 | 6 | Copper sleeve kit |
| -85104134 | |||
| 12 | 20536487 | 6 | O-ring |
| -3165747 | |||
| 13 | 968062 | 2 | Plug |
| 14 | 422426 | 1 | Pin |
| 15 | 20441335 | 1 | Plug |
| 16 | 8170553 | 1 | Expansion plug |
| 17 | 3165025 | 12 | Plug |
| 18 | 949659 | 12 | O-ring |
| 19 | 20463179 | 1 | Adapter |
| 20 | 949721 | 2 | O-ring |
| 21 | 1544710 | 1 | Sealing ring |
| 22 | 21345131 | 38 | Flange screw |
| 23 | 21344784 | 9 | Stud |
| 24 | 20545669 | 1 | Valve cover |
| Without oil filler cap | |||
| 24 | 8170115 | 1 | Valve cover |
| With oil filler cap, Repl by 20545669 | |||
| 25 | 20807510 | 1 | Oil filler cap |
| -1675839 | |||
| 26 | 1675841 | 1 | Gasket |
| 27 | 21070576 | 1 | Sealing strip |
| 28 | 3964604 | 16 | Bushing |
| 29 | 8148488 | 16 | Cap nut |
| 30 | 3099100 | 1 | Cylinder head gasket, cylinder head |
| 31 | 20489341 | 1 | Seal |
| 32 | 3828003 | 1 | Cap |
| 33 | 946440 | 2 | Flange screw |
| 34 | 3826657 | 1 | Lifting eye |
| 35 | 959265 | 3 | Hex. socket screw |
| 36 | 940280 | 3 | Spring washer |
| 37 | 950562 | 14 | Pin |
| Included in overhaul kit 3165309. | |||
| 38 | 3830718 | 1 | Gasket kit |
| See group 99 | |||
| 38 | 3165309 | 1 | Bearing housing |
| See group 99 | |||
| 39 | 8131707 | 11 | Cap plug |
| 40 | 947281 | 1 | Gasket |
