| # | Part no | Qty | Description |
| 1 | 3588798 | 1 | Oil pan |
| 2 | 468940 | 1 | Hose connection |
| 3 | 468947 | 1 | Rubber washer |
| 4 | 468948 | 2 | Hexagon nut |
| 5 | 20571854 | 1 | Magnetic plug |
| -20556987 | |||
| 6 | 20579690 | 1 | Sealing ring |
| -20556989 | |||
| 7 | 1 | Retainer | |
| Included in repair kit 3809423. | |||
| 8 | 949721 | 1 | O-ring |
| Included in repair kit 3809423. | |||
| 9 | 1 | Washer | |
| Included in repair kit 3809423. | |||
| 10 | 1 | Hexagon nut | |
| Included in repair kit 3809423. | |||
| 11 | 949658 | 1 | O-ring |
| Included in repair kit 3807335. | |||
| 12 | 3588389 | 1 | Retainer |
| Included in repair kit 3807335. | |||
| 13 | 479977 | 1 | Plug |
| 14 | 20364258 | 1 | Washer |
| Included in repair kit 3807335. | |||
| 15 | 3588391 | 1 | Hexagon nut |
| Included in repair kit 3807335. | |||
| 16 | 468947 | 1 | Rubber washer |
| 17 | 20532272 | 1 | Sealing strip |
| 18 | 20463185 | 14 | Flange screw |
| 19 | 14 | Spring sleeve | |
| 20 | 8170261 | 1 | Oil pump |
| 20 | 1 | ||
| 21 | 8170878 | 1 | Suction pipe |
| 22 | 465784 | 1 | Sealing ring |
| 23 | 965180 | 3 | Flange screw |
| L=60mm | |||
| 24 | 968842 | 1 | Flange screw |
| L=110mm | |||
| 25 | 471734 | 4 | Flange screw |
| 26 | 20411298 | 1 | Pressure pipe |
| 27 | 1 | Nut | |
| 28 | 1 | Ferrule | |
| 29 | 8170558 | 1 | Sealing ring |
| 30 | 3155151 | 6 | Piston cooling jet |
| 31 | 966378 | 6 | Flange screw |
| 32 | 8170583 | 1 | Nozzle, transmission |
| 33 | 471586 | 1 | Screw |
| 34 | 8170702 | 1 | Spacer |
| 35 | 1636309 | 1 | Sealing ring |
| 36 | 8193971 | 1 | Outlet pipe |
| 37 | 3165142 | 2 | Flange screw |
| 38 | 1677370 | 2 | Sealing ring |
| 39 | 3807498 | 1 | Oil dipstick |
| 40 | 925054 | 1 | O-ring |
| 41 | 3839161 | 1 | Pipe |
| 42 | 20808092 | 1 | Oil filler pipe |
| -8149086 | |||
| 43 | 20807510 | 1 | Oil filler cap |
| -3154328 | |||
| 44 | 20365079 | 1 | Rubber washer |
| 45 | 3831383 | 1 | Hose |
| 46 | 943476 | 2 | Hose clamp |
| 47 | 3831384 | 1 | Bracket |
| 48 | 977938 | 2 | Flange lock nut |
| 49 | 949997 | 2 | Clamp |
| 50 | 946440 | 2 | Flange screw |
| 51 | 945408 | 2 | Flange nut |
