| 序号 | 配件号码 | 配件名称 | 外文名称 | 配件型号 | 数量 |
| 1 | 27130104141 | 左挡泥瓦总成 | Left fender assembly | 1 | |
| 10 | 27130102161 | 雾灯护罩 | Fog light protecting cap | 2 | |
| 11 | 4015000110 | 垫圈GB97.1-5EpZn-300HV | washer | GB97.1-5EpZn-300HV | 8 |
| 12 | 4011000586 | 螺栓GB16674-M5*25EpZn-8.8 | screw | GB16674-M5*25EpZn-8.8 | 8 |
| 13 | 4011000594 | 螺栓GB5783-M16*60EpZn-8.8 | screw | GB5783-M16*60EpZn-8.8 | 8 |
| 14 | 4015000001 | 垫圈GB1230-16EpZn-45 | washer | GB1230-16EpZn-45 | 8 |
| 15 | 4015000181 | 垫圈GB97.1-16EpZn-300HV | washer | GB97.1-16EpZn-300HV | 2 |
| 16 | 27130104411 | 调整垫片 | Trim washer | 2 | |
| 17 | 4011000512 | 螺栓GB5785-M16*1.5*50EpZn-8.8 | bolt | GB5785-M16*1.5*50EpZn-8.8 | 2 |
| 18 | 4013010121 | 螺母GB6185-M14EpZn-8 | Nut gb6185-m14epzn-8 | MT86 | 25 |
| 19 | 27130102491 | 前接支架支撑座 | Front support base | 1 | |
| 2 | 4011000207 | 螺栓GB5783-M12*45EpZn-8.8 | bolt | GB5783-M12*45EpZn-8.8 | 7 |
| 20 | 4011010254 | 螺栓GB5783-M14*55EpZn-8.8 | Bolt gb5783-m14*55epzn-8.8 | 11 | |
| 21 | 27130103921 | 前台架支撑架 | Support bracket | 1 | |
| 22 | 27130103911 | 胶垫 | Rubber mat | 10 | |
| 23 | 27130113171 | 调整垫片1 | Adjustment shim 1 | 3 | |
| 24 | 27130113181 | 调整垫片2 | Adjustment shim 2 | 3 | |
| 25 | 27130107001 | 中台架 | Intermediate stand | 1 | |
| 26 | 4011000338 | 螺栓GB5783-M14*50EpZn-8.8 | screw | GB5783-M14*50EpZn-8.8 | 4 |
| 27 | 4015000177 | 垫圈GB97.1-14EpZn-300HV | washer | GB97.1-14EpZn-300HV | 11 |
| 28 | 4015000188 | 垫圈GB96.1-14EpZn-300HV | washer | GB96.1-14EpZn-300HV | 20 |
| 29 | 27360109211 | 后台架总成 | Support | 1 | |
| 3 | 4013010120 | 螺母GB6185-M12EpZn-8 | Nut gb6185-m12epzn-8 | MT86 | 8 |
| 30 | 27130104101 | 右挡泥瓦总成 | Right fender assembly | 1 | |
| 31 | ZJ4190003193 | 固定式右侧平台（86） | Right fixed platform | 1 | |
| 32 | 4011000420 | P-螺栓GB5782-M14*90EpZn-8.8 | Bolt | 10 | |
| 33 | 4011000092 | 螺栓GB5783-M12*50EpZn-8.8 | bolt | GB5783-M12*50EpZn-8.8 | 1 |
| 4 | 4013000016 | 螺母GB6170-M16EpZn-8 | nut | GB6170-M16EpZn-8 | 8 |
| 5 | 4015000305 | 垫圈GB96.1-16EpZn-300HV | retaining ring | 8 | |
| 6 | 27130107671 | 调整垫片1 | Trimmed gasket | 4 | |
| 7 | 27130107681 | 调整垫片2 | Trimmed gasket | 4 | |
| 8 | 4013000118 | 螺母GB6170-M5EpZn-8 | nut | GB6170-M5EpZn-8 | 8 |
| 9 | 27130114151 | 保险杆总成 | Bumper assembly | 1 |
