K2-2926000800 后车架总成 REAR FRAME LG933L SDLG WHEEL LOADER
1 29260008004 后车架 REAR FRAME Y 1
2 29270007841 副车架 OSCILLATING FRAME Y 1
3 29270007971 后转向销 REAR PIN OF STEERING CYLINDER Y 2
4 4011000197 螺栓GB5783-M12*25EpZn-8.8 BOLT GB5783-M12*30EpZn-8.8 N 6
5 4015000026 垫圈GB93-12-65Mn WASHER GB93-12-65Mn N 4
6 29250001061 开槽螺母 SLOTTED NUT Y 1
7 4016000113 开口销GB91-6.3*63EpZn-Q235A SPLIT PIN GB91-6.3*63EpZn-Q235A N 1
8 2110900005 下铰接销 DOWN ARTICULATION PIN Y 1
9 29270008001 油管总成 TUBE ASSEMBLY Y 1
10 4040000002 垫圈LGB001-16 WASHER LGB001-16 Y 1
11 4011000417 螺栓GB5783-M20*35EpZn-8.8 BOLT GB5783-M20*35EpZn-8.8 N 1
12 4015000030 垫圈GB93-20-65Mn WASHER GB93-20-65Mn N 1
13 4015000176 垫圈GB97.1-20EpZn-300HV WASHER GB97.1-20EpZn-300HV N 1
14 2110900052 油孔引出管 TUBE
1
15 2110900006 上铰接销 UP ARTICULATION PIN Y 1
16 2110900007 副车架油管 OIL TUBE OF OSCILLATING FRAME Y 1
17 29270001051 调整垫片 ADJUST SPACER Y 2
18 29270007831 套 BUSH Y 2
19 29270008591 焊接销轴 JOINTING PIN Y 2
20 4016000222 销轴GB882-B30*80EpZn-35 PIN GB882-B30*80EpZn-35 N 2
21 4016000040 开口销GB91-6.3*50EpZn-Q235A SPLINT PIN GB91-6.3*50EpZn-Q235A N 2
22 29270008891 锁定杆 MOUNT BAR Y 1
23 29270008611 左盖板 PLATE Y 1
24 2110900524 右盖板 PLATE Y 1
25 2110900225 滤清器支架 FILTER BRACKET Y 1
26 4011000093 螺栓GB5783-M16*25EpZn-8.8 BOLT GB5783-16*25EpZn-8.8 N 1
27 29270009101 走线胶套 RUBBER SLOEVE Y 2
28 4030000065 油杯JB7940.1-M10*1 GREASE NIPPLE JB7940.1-M10*1 Y 5
29 4011000560 螺栓GB16674-M12*25EpZn-8.8 BOLT GB16674-M12*25EpZn-8.8 N 2
30 3110900177 卡板 PLATE Y 2
31 4011000102 螺栓GB5783-M8*16EpZn-8.8 BOLT GB5783-M8*16EpZn-8.8 N 8
32 4040000001 垫圈LGB001-12 WASHER LGB001-12*45*6 Y 2
33 29270007821 橡胶套 RUBBER BUSH Y 1
34 29270007541 橡胶套 RUBBER BUSH Y 3
35 4015000256 垫圈GB96.1-8EpZn-300HV WASHER GB96.1-8EpZn-300HV N 8
36 4043000064 垫片LGB303-40*70*1 SPACER LGB303-40*70*1 Y 4
37 4043000325 垫片LGB303-40*70*2 SPACER LGB303-40*70*2 Y 4
38 29270001061 调整垫片 ADJUST SPACER Y 2
39 29270001071 调整垫片 ADJUST SPACER Y 2
40 29040007801 滤清器支架 FILTER BRACKET Y 1
41 29270009311 调整垫片 ADJUSTING SHIM N 2
42 29270009321 调整垫片 ADJUSTING SHIM N 2
43 29270009331 调整垫片 ADJUSTING SHIM N 2
