SDLG LG936L WHEEL LOADER 转斗缸总成 TILT CYLINDER ASSEMBLY
1 4011000081 螺栓GB5783-M10*20EpZn-8.8 BOLT GB5783-M10*20EpZn-8.8 N 2
2 29140009881 放平护板 INDICATING ROD OF BUCKET Y 1
3 4011000145 螺栓GB16674-M14*35EpZn-8.8 BOLT GB16674-M14*35EpZn-8.8 N 2
4 4013000013 螺母GB6170-M14EpZn-8 NUT GB6170-M14EpZn-8 N 2
5 4120001083 转斗油缸HSGF-140*80*502-952P TILT CYLINDER HSGF-140*80*502-952P Y 1
6 29140008371 转斗指示板 INDICATION ROD OF TILT CYLINDER Y 1
7 4011000080 螺栓GB5783-M10*16EpZn-8.8 BOLT GB5783-M10*16EpZn-8.8 N 2
8 29140007581 接近开关支架 BRACKET OF APPROACH SWITCH Y 1
9 4011000479 螺栓GB16674-M12*30EpZn-8.8 BOLT GB16674-M12*30EpZn-8.8 N 2
10 4041000774 螺塞LGB135-01422 PLUG LGB13501421 Y 1
11 4041000767 O形圈LGB168-11124 O-RING LGB168-11124 Y 1
12 29140008441 转斗缸大腔钢管 BIG CHAMBER TUBE OF TILT CYLINDER Y 1
13 4011000309 螺栓GB16674-M10*50EpZn-8.8 BOLT GB16674-M10*50EpZn-8.8 N 2
14 4011000473 螺栓GB16674-M10*55EpZn-8.8 BOLT GB16674-M10*55EpZn-8.8 N 2
15 4030000026 O形圈GB3452.1-32.5*3.55G O-RING GB3452.1-32.5*3.55G Y 5
16 4041000939 软管LGB106-410120 PIPE LGB106-410120 Y 2
17 4041000043 分体法兰LGB117-310490 FLANGE LGB117310490 Y 4
18 4011000475 螺栓GB16674-M10*30EpZn-8.8 BOLT GB16674-M10*30EpZn-8.8 N 24
19 29140007541 接近开关支架 FRAME OF ADJACENT SWICH Y 1
20 4130000678 接近开关J7-D10B1/08 APPROACH SWITCH J7-D10B1/08 Y 1
21 29140007551 动臂指示板 INDICATIONG PLATE OF LIFTING CYLINDER Y 1
22 4011000137 螺栓GB16674-M12*20EpZn-8.8 BOLT GB16674-M12*20EpZn-8.8 N 4
23 4011000105 螺栓GB5783-M8*20EpZn-8.8 BOLT GB5783-M8*20EpZn-8.8 N 4
24 29140008401 转斗联小腔钢管 OIL TUBE OF SMALL CHAMBEROF TILT CYLINDER Y 1
25 4030000029 O形圈GB3452.1-37.5*3.55G O-RING GB3452.1-37.5*3.55G Y 2
26 4041000027 分体法兰LGB117-312551 FLANGE LGB117312551 Y 2
27 29140008411 转斗联大腔钢管 OIL TUBE OF BIG CHAMBEROF TILT CYLINDER Y 1
28 4015000162 垫圈GB97.1-10EpZn-300HV WASHER GB97.1-10EpZn-300HV N 6
29 4013000007 螺母GB6170-M10EpZn-8 NUT GB6170-M10EpZn-8 N 4
30 4041000958 U形螺栓LGB159-03040 U-BOLT LGB159-03040 Y 2
31 29140004061 固定支架A STEADY REST A Y 1
32 29140004071 固定支架B STEADY REST B Y 1
33 4130000011 中间继电器JD2914 MIDDLE RELAY JD2914 Y 2
34 4014000048 螺钉GB818-M5*12EpZn-4.8 SCREW GB818-M5*12EpZn-4.8 N 2
35 4015000110 垫圈GB97.1-5EpZn-300HV WASHER GB97.1-5EpZn-300HV N 2
36 4015000072 垫圈GB97.1-8EpZn-300HV WASHER GB97.1-8EpZn-300HV N 4
37 4130000010 接近开关J7-D10B1 APPROACH SWITCH J7-D10B1 Y 1
38 4015000197 垫圈GB96.1-10EpZn-300HV WASHER GB96.1-10EpZn-300HV N 2
