SDLG LG936L WHEEL LOADER 发动机总成 DIESEL ENGINE ASS’Y
1 4110000587 发动机总成TD226B-6IG15(13040183) DIESEL ENGINE ASSEMBLY TD226B-6IG15(13040183) Y 1
2 4013000028 螺母GB6170-M6EpZn-8 NUT GB6170-M6EpZn-8 N 5
3 4015000207 垫圈GB97.1-6EpZn-300HV WASHER GB97.1-6EpZn-300HV N 2
4 4030000521 胶管JB8406-B16*1500 RUBBER TUBE JB8406-B16X1500 Y 1
5 4120000049 胶管JB8406-B16*2600 RUBBER TUBE JB8406-B16X2600 Y 1
6 4041000829 管夹LGB167-0322 CLAMP LGB167-0322 Y 1
7 4041000876 缓冲套LGB123-0322 BUSH LGB123-0322 Y 1
8 4011000461 螺栓GB16674-M8*16EpZn-8.8 BOLT GB16674-M8*16EpZn-8.8 N 1
9 4120000067 暖风机水阀LG12-NFJSF VALVE-HEATER Y 2
10 4017000024 环箍QC390-D26 CLAMP QC390-D26 N 6
11 29010013441 操纵软轴 CABLE SHAFT Y 1
12 4120000096 油门踏板ZY75-00 ACCELERATOR PEDAL ZY75-00 Y 1
13 4011000101 螺栓GB5783-M6*20EpZn-8.8 BOLT GB5783-M6*20EpZn-8.8 N 3
14 4015000035 垫圈GB93-6-65Mn WASHER GB93-6-65Mn N 3
15 4013000033 螺母GB6170-M8EpZn-8 NUT GB6170-M8EpZn-8 N 1
16 29010006681 连接叉 JOINT FORK Y 1
17 4016000138 销轴GB882-B6*22EpZn-35 PIN GB882-B6*22EpZn-35 N 2
18 4016000100 开口销GB91-2*20EpZn-Q235A SPLINT PIN GB91-2*20EpZn-Q235A N 2
19 4016000120 开口销GB91-2*12EpZn-Q235A SPLINT PIN GB91-2*12EpZn-Q235A N 1
20 29010001071 螺栓轴 BOLT SHAFT Y 1
21 4014000020 螺钉GB75-M6*10EpZn-22H SCREW GB75-M6*10EpZn-22H N 1
22 29010009212 操纵软轴 CABLE SHAFT Y 1
23 29220001191 直接头 CONNECTOR Y 2
24 29010008701 输油胶管 TUBE PIPE Y 1
25 4041001214 软管LGB145-205155 HOSE LGB145-205155 Y 1
26 29010008691 回油接头 FITTING OIL RETURN Y 1
27 29010000111 双头螺柱 DOUBLE BOLT Y 12
28 4013000007 螺母GB6170-M10EpZn-8 NUT GB6170-M10EpZn-8 N 12
29 4015000025 垫圈GB93-10-65Mn WASHER GB93-10-65Mn N 12
30 4011000455 螺栓GB16674-M8*25EpZn-8.8 BOLT GB16674-M8*25EpZn-8.8 N 2
31 29220007571 支架 BRACKET Y 1
32 4120000084 油水分离器组合阀ST-50G AIR DYER ST-50G Y 1
33 4120000750 金属软管 METAL TUBE Y 1
34 29220000171 垫圈 WASHER Y 2
35 29010006621 接头螺钉 SCREW Y 2
36 29010006631 垫圈 WASHER Y 4
37 4011000236 螺栓GB5782-M20*130EpZn-8.8 BOLT GB5782-M20*130EpZn-8.8 N 2
38 4013000020 螺母GB6170-M20EpZn-8 NUT GB6170-M20EpZn-8 N 2
39 4015000176 垫圈GB97.1-20EpZn-300HV WASHER GB97.1-20EpZn-300HV N 2
40 4015000030 垫圈GB93-20-65Mn WASHER GB93-20-65Mn N 2
41 29050000101 减震块 SHOCK MOUNT Y 4
42 29050000121 垫圈 WASHER Y 4
43 29010008841 压力传感器接头 PRESSURE SENSOR Y 1
44 4011000081 螺栓GB5783-M10*20EpZn-8.8 BOLT GB5783-M10*20EpZn-8.8 N 6
45 4015000197 垫圈GB96.1-10EpZn-300HV WASHER GB96.1-10EpZn-300HV N 6
46 29010015531 上盖板 UP HOOD Y 1
