SDLG LG953 WHEEL LOADER 液压操纵总成 HYDRAULIC CONTROL ASSENBLY
1 4120000703 多路阀DF32-18 CONTROL VAVLE DF32-18 Y 1
2 29120009141 多路阀固定板 MOUNTED PLATE OF MULTIPLE UNIT VALVE Y 1
3 4011000477 螺栓GB16674-M12*35EpZn-8.8 BOLT GB16674-M12*35EpZn-8.8 N 4
4 4015000168 垫圈GB97.1-12EpZn-300HV WASHER GB97.1-12EpZn-300HV N 8
5 4013000011 螺母GB6170-M12EpZn-8 NUT GB6170-M12 EpZn-8 N 8
6 4011000056 螺栓GB5782-M12*145EpZn-8.8 BOLT GB5782-M12*145EpZn-8.8 N 3
7 4011000058 螺栓GB5782-M12*175EpZn-8.8 BOLT GB5782-M12*175EpZn-8.8 N 1
8 4011000230 螺栓GB16674-M10*65EpZn-8.8 BOLT GB16674-M10*65EpZn-8.8 N 1
9 29120009161 多路阀回油钢管 RENTURN TUBE OF MULTIPLE UNIT VALVE Y 1
10 4041000011 分体法兰LGB117-314650 FLANGE LGB117-314650 Y 2
11 4030000130 O形圈GB3452.1-47.5*3.55G O-RING GB3452.1-47.5*3.55G Y 2
12 29120015331 回油胶管 HOSE Y 1
13 4011000455 螺栓GB16674-M8*25EpZn-8.8 BOLT GB16674-M8*25EpZn-8.8 N 4
14 29120009121 支架 SHELF Y 1
15 4011000053 螺栓GB5782-M10*90EpZn-8.8 BOLT GB5782-M10*90EpZn-8.8 N 2
16 4013000007 螺母GB6170-M10EpZn-8 NUT GB6170-M10EpZn-8 N 2
17 4015000162 垫圈GB97.1-10EpZn-300HV WASHER GB97.1-10EpZn-300HV N 2
18 29120009091 压板 PRESS PLATE Y 1
19 29120009101 橡胶板 RUBBER PLATE Y 2
20 4040000001 垫圈LGB001-12 WASHER LGB001-12*45*6 Y 2
21 29120014961 多路阀进油块 OIL INPUT BLOCK OF CONTROL VAVLE Y 1
22 4030000029 O形圈GB3452.1-37.5*3.55G O-RING GB3452.1-37.5*3.55G Y 3
23 4011000136 螺栓GB16674-M10*85EpZn-8.8 BOLT GB16674-M10*85EpZn-8.8 N 4
24 4041000774 螺塞LGB135-01422 PLUG LGB13501421 Y 2
25 4041000767 O形圈LGB168-11124 O-RING LGB168-11124 Y 2
26 29120014981 多路阀进油胶管 OIL INPUT PIPE OF CONTROL VAVLE Y 1
27 4041000056 分体法兰LGB117-312550 FLANGE LGB117-312550 Y 2
28 4011000475 螺栓GB16674-M10*30EpZn-8.8 BOLT GB16674-M10*30EpZn-8.8 N 12
29 29120001401 操纵软轴 CONTROL AXIS Y 2
30 4120001019 操纵机构LG12-953CZJG01 OPERATING GEAR LG12-953CZJG01 Y 1
31 29120009111 护板 COVER SHEET Y 1
32 29120000071 销轴 PIN Y 2
33 4016000035 开口销GB91-4*20EpZn-Q235A SPLIT PIN 4*20 N 2
34 29120000081 铰接头 JOINT HEAD Y 2
35 4030000031 O形圈GB3452.1-42.5*3.55G O-RING GB3452.1-42.5*3.55G Y 1
36 4011000479 螺栓GB16674-M12*30EpZn-8.8 BOLT GB16674-M12*30EpZn-8.8 N 8
