举升缸总成 LIFT ARM CYLINDER ASSEMBLY SDLG LG969 WHEEL LOADER
1 4120000600 动臂油缸HSGF-180*100*798-1348 LIFTING CYLINDER HSGF-180*100*798-1348 Y 2
2 29130012441 左动臂缸小腔钢管
SMALL CHAMBER TUBE OF LEFT LIFT ARM
CYLINDER
Y 1
3 4011000473 螺栓GB16674-M10*55EpZn-8.8 BOLT GB16674-M10*55EpZn-8.8 N 8
4 4011000309 螺栓GB16674-M10*50EpZn-8.8 BOLT GB16674-M10*50EpZn-8.8 N 8
5 4030000026 O形圈GB3452.1-32.5*3.55G O-RING GB3452.1-32.5*3.55G Y 10
6 29130010861 动臂联大腔三通钢管 THREE-WAY OIL TUBE Y 1
7 4011000475 螺栓GB16674-M10*30EpZn-8.8 BOLT GB16674-M10*30EpZn-8.8 N 56
8 4030000029 O形圈GB3452.1-37.5*3.55G O-RING GB3452.1-37.5*3.55G Y 6
9 29130010891 阀至左动臂缸大腔钢管 OIL TUBE OF LIFTING CYLINDER (L) Y 1
10 29130012111 左支架 LEFT BEARER Y 1
11 4011000479 螺栓GB16674-M12*30EpZn-8.8 BOLT GB16674-M12*30EpZn-8.8 N 6
12 29130010961 阀至左动臂缸小腔钢管 OIL TUBE OF LIFTING CYLINDER (L) Y 1
13 29130011001 钢管支架 BRACKET Y 1
14 4011000474 螺栓GB16674-M10*25EpZn-8.8 BOLT GB16674-M10*25EpZn-8.8 N 3
15 29130010981 动臂联小腔三通钢管 THREE-WAY OIL TUBE Y 1
16 4041001141 U形螺栓LGB159-03646 U-BOLT LGB159-03646 Y 1
17 4041001142 底板LGB160-3646 PADDING LGB160-3646 Y 1
18 4015000162 垫圈GB97.1-10EpZn-300HV WASHER GB97.1-10EpZn-300HV N 14
19 4013000007 螺母GB6170-M10EpZn-8 NUT GB6170-M10EpZn-8 N 14
20 4041000958 U形螺栓LGB159-03040 U-BOLT LGB159-03040 Y 6
21 4041001018 底板LGB160-3040 PLATE LGB160-3040 Y 6
22 29130010571 动臂缸胶管 OIL PIPE OF LIFTING CYLINDER Y 4
23 4041000043 分体法兰LGB117-310490 FLANGE LGB117310490 Y 8
24 29130000111 管夹 CLAMP Y 2
25 4011000458 螺栓GB16674-M8*20EpZn-8.8 BOLT GB16674-M8*20Ep.Zn-8.8 N 8
26 29130000051 右动臂缸大腔钢管
OIL TUBE TO BIG CHAMBER OF RIGHT LIFTING
CYLINDER
Y 1
27 4011000488 螺栓GB16674-M10*16EpZn-8.8 BOLT GB16674-M10*16EpZn-8.8 N 2
28 29130010371 管夹 CLAMP Y 8
29 4041000869 缓冲套LGB123-0740 CUSHION LGB123-0740 Y 8
30 4013000033 螺母GB6170-M8EpZn-8 NUT GB6170-M8EpZn-8 N 4
31 4015000072 垫圈GB97.1-8EpZn-300HV WASHER GB97.1-8EpZn-300HV N 4
32 29130000031 左动臂缸大腔钢管
OIL TUBE TO BIG CHAMBER OF LEFT LIFTING
CYLINDER
Y 1
33 29130010941 阀至右动臂缸小腔钢管 OIL TUBE OF LIFTING CYLINDER (R) Y 1
34 29130010921 阀至右动臂缸大腔钢管 OIL TUBE OF LIFTING CYLINDER (R) Y 1
35 29130012461 右动臂缸小腔钢管 RIGHT LIFTING CYLINDER SMALL CHAMBER TUBE Y 1
36 29130012131 右支架 RIGHT BEARER Y 1
