612600010735复合垫圈Washer

90003962051六角螺塞Hexagonplug

90003989288碗形塞Coreholeplug

61500010100后油封Rearoilseal

612600050042密封垫圈Sealwasher

612600011927螺塞Screwplug

614070068安全阀弹簧Safetyvalvespring

614070069安全阀Safetyvalve

612630010015气缸套Cylinderliner

61560010047喷嘴组件Nozzleassembly

90003098015密封垫圈Sealwasher

90003962621空心螺栓Hollowbolt

90003802493六角头螺栓Hexagonbolt

90003962050内六角螺塞Innerhexagonplug

AZ1500070097主油道限压阀总成Pressurelimitingvalveassembly ofmainoilpassage

90003862428内六角圆柱头螺钉Innerhexagonscrew

188250083自锁垫圈Washer

612600013918下止推片Thrustwasher(lower)

612600013917上止推片Thrustwasher(upper)

81400010032密封圈Sealwasher

81500010046主轴瓦组件MainBearingSet

90003901604圆柱销Straightpin

90003909626弹性圆柱销Springdowelpin

61500010185S气缸盖螺栓Cylinderheadbolt

612600013774气缸体预装配Pre-assembledcylinderblock

90003982121碗形塞Corehole plug

612600013437拉铆钉Tensione drivet

612600013705气缸体Cylinder block

90003989215碗形塞Corehole plug

90003989289碗形塞Corehole plug

612600013731曲轴箱Crank shaft case

614010217主轴承螺栓Main bearing bolt

614010114主轴承螺栓Main bearing bolt

90003901604A圆柱销Straight pin

612600010991凸轮轴衬套Camshaft bushing

61560010029凸轮轴衬套Camshaft bushing

90003989204碗形塞Corehole plug

90003989210碗形塞Corehole plug

61000010134密封圈Seal washer

612600011783正时齿轮室 Timing gear case

612600013483六角法兰面承面带齿螺栓Hexagon Flange Bolt

90011430008六角法兰面承面带齿螺栓 Hexagon Flange Bolt

61500010037前油封Oil seal(front)

612600010735复合垫圈Washer

90014400019密封垫圈Seal washer

90003802402六角头螺栓Hexagon bolt

90003962051六角螺塞Hexagon plug

288730061 O型密封圈 O shaped seal washer

90003901418圆柱销Straight pin

612600012830盖板Cover shield

90011430008六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600080201密封垫圈Seal washer

90011430016六角法兰承面带齿螺栓Toothed bolt

90003862427内六角圆柱头螺钉Inner hexagon screw

612600061711六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600010564指针Pointer

90011430029六角法兰面承面带齿螺栓Hexagon Flange Bolt

90003120602密封圈Seal washer

612600111639管夹总成PipeClampAssembly

612600114377六角法兰面承面带齿螺栓HexagonFlangeBolt

612600013168油气分离器组件Oil-gasseparatorassembly

612600012859油路连接胶管OilConnectingRubberPipe

90003989300卡箍Clamp

612600012595回油管接头Fuelreturnpipenipple

90011270002六角头螺栓全螺纹Hexagonbolt,fullthreadM10×30GB/T5783-10.9-Zn.D

90003931122弹簧垫圈Springwasher

612600011361管夹总成PipeClampAssembly

612600012525油路连接胶管OilConnectingRubberPipe

90003989340卡箍Clamp

614010279通风弯管Ventilating elbow

90003069303垫片Gasket

612600010172油气分离器Oil-gas separator

90003932023波形弹性垫圈Wave spiral washer

90003862427内六角圆柱头螺钉Inner hexagon screw

612600011263油标尺Dipstick

612600013199油尺管组件Dipstick tube assembly

612600011615机油尺管下组件Oil dipstick tube assembly(lower)

90011430015六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600014006加机油管组件Oil filling pipe assembly

614010086垫片Gasket

1612600020722  曲轴总成 Crank shaft assembly

90015050017圆柱销Straight pin

612600020866曲轴Crank shaft

612600020311堵塞Plug

612600020040平键Flat key

612600020723曲轴正时齿轮Timing gear of crank shaft

612600020608法兰Flange

615T1020046飞轮螺栓Fly wheel bolt

612600020636飞轮总成Fly wheel assembly

612600020165联接盘Adaptor

612600020637飞轮齿圈Fly wheel ring gear

615T1020030飞轮Fly wheel

90003802578六角头螺栓Hexagon bolt

612600020730曲轴皮带轮Crank shaft belt pulley

612600020833扭振减振器Torsion vibration damper

81560030012活塞销挡圈Piston pin retainer

61560030013活塞销Piston pin

612600030020连杆上瓦Connecting Rod Upper Shell

61560030033连杆下瓦Connecting Rod Lower Shell

61500030009连杆总成Connecting rod assembly

612600030010活塞Piston

612600030051活塞环组件Piston ring assembly

61500030077连杆衬套Connecting rod bushing

61500030008连杆体Connecting rod body

61500030022连杆盖Connecting rod cover

81500030023连杆螺栓Connecting rod bolt

61560030047梯形环Key stone ring

612600030019扭曲锥面环Conical ring

61560030045油环Oil ring

61500040012吊环夹紧块Hoisting ring clamping block

61200040027夹紧块Clamping block

612600040114气门阀杆密封套Seal washer of valve stem

612600040355气缸盖衬垫Cylinder head gasket

61560040040A气缸盖分总成Cylinder head sub assembly

61200040023夹紧块Clamping block

615G00040012B吊环夹紧块Hoisting ring clamping block

61200040034带肩螺母Nut

612600040020吊环接块Hoisting ring plate

614010388吊环螺钉Eye screw

61500040009夹紧块Clamping block

612600040452气缸盖主螺栓Cylinder head main bolt

612600040099喷油器衬套 Injector bushing

406060010环状密封圈25.2*3DR100N05040 Seal washer

90003989294碗形塞Corehole plug

81560040037排气门座Exhaust valve seat

61560040057进气门座Intake valve seat

61560040040B气缸盖Cylinder head

90003989721碗形塞片Corehole plug

90003989277碗形塞片Corehole plug

90003989725碗形塞片Corehole plug

612600040113 气门导管 Valve guide

612600040636六角法兰面螺栓Hexagon Flange Bolt

614040065气缸盖罩Cylinder head cover

614040021气缸盖罩衬垫Cylinder head cover gasket

612600050178排气门摇臂总成

61500040014排气门弹簧下座Exhaust valve spring seat(lower)

612600050025排气门Exhaust valve

61500050032气门挺柱Tappet

614050133凸轮轴止推片Camshaft thrust

90003802399S六角头螺栓Hexagon bolt

612600050085凸轮轴总成Camshaft assembly

614050053凸轮轴正时齿轮Camshaft timing gear

612600050145S六角头螺栓Hexagon bolt

61560050059S六角头螺栓Hexagon bolt

61560050045垫片Gasket

61560050058轴Shaft

61560050053中间齿轮总成Intermediate gear assembly

61560050044中间齿轮轴Intermediate gear shaft

612600050210推杆Pushrod

612600050073进气门Intake valve

614050017进气门弹簧下座Intake valves pring seat(lower)

61500050002气门外弹簧Outer valve spring

61500050001气门内弹簧Inner valve spring

61500050109气门弹簧上座Valve spring seat(upper)

61500050025气门锁夹Valve collet

61500050105气门帽Valve cap

612600050177进气门摇臂总成Intake valve rocker arm

614050119气门摇臂座Valve rocker arm seat

90003802655六角头螺栓Hexagon bolt

61500050096凸轮轴Camshaft

90003901409圆柱销Straight pin

61560050052中间齿轮Intermediate gear

61560050051衬套Bushing

2130050065气门间隙调整螺母Valve adjusting nut

614050048进气摇臂Intake Rocker Arm

614050010气门间隙调整螺钉Valve Adjusting Bolt

2130050065气门间隙调整螺母Valve adjusting nut

614050049排气门摇臂Exhaust valve rocker arm

614050010气门间隙调整螺钉Valve Adjusting Bolt

90017020004六角头螺塞Hexagon plug

13023364组合密封垫圈Unit seal washer

90017010003方头锥型螺塞

612600080246密封垫圈Seal washer

612600040563出水管Water outlet pipe

13023361组合密封垫圈Unit seal washer

90003962014六角螺塞Hexagon plug

61564D040010管接头组件Adapter assembly

612600040016螺堵Plug

90003932023波形弹性垫圈Wave spiral washer

90003800466六角头螺栓Hexagon bolt

612600040549中间接头

90017020003六角头螺塞Hexagon plug

612600060518冷却液连接胶管Coolant Connecting Rubber Pipe

90003989308卡箍Clamp

615G00060016节温器总成Thermostat assembly

612600061840胶管Rubber pipe

90003813429S双头螺柱Stud

90003813470S双头螺柱Stud

614060008水泵密封垫 Seal gasket of water pump

612600061739水泵 Water pump

612600061719 6六角法兰面承面带齿螺母 Hexagon Flange Nut

615G00060001水管接头垫片Gasket

612600062113进水管接头Water Inlet Pipe Connector

90003932023波形弹性垫圈Wave spiral washer

90003802424六角头螺栓Hexagon bolt

90003800467六角头螺栓Hexagon bolt

612600040016螺堵Plug

90011430012六角法兰面承面带齿螺栓Hexagon Flange Bolt

615T1-3100011支架板Bracket plate

612600061720六角法兰面承面带齿螺母Hexagon Flange Nut

612600100143风扇托架总成Fan bracket assembly

612600100135垫板组件

612600061711六角法兰面承面带齿螺栓Hexagon Flange Bolt

90011430032六角法兰面承面带齿螺栓Hexagon Flange Bolt

90011430036六角法兰面承面带齿螺栓Hexagon Flange Bolt

90011430009六角法兰面承面带齿螺栓Hexagon Flange Bolt

90003800619六角头螺栓Hexagon bolt

612600100050风扇Fan

90012290003六角法兰面螺母Hexagon Flange Nut

612600061785惰轮支架Idle wheel bracket

615G60110033调整垫圈Adjusting washer

612600061713六角法兰面承面带齿螺栓Hexagon Flange Bolt

90011430009六角法兰面承面带齿螺栓Hexagon Flange Bolt

90011430007S六角法兰面承面带齿螺栓Hexagon Flange Bolt

612630060836发电机惰轮Idle wheel

612600061464多楔带Ribbed belt

612600061295多楔带Ribbed belt

90011260010六角头螺栓Hexagon bolt

612600061256皮带张紧轮Belt tightener

612630060838皮带惰轮10槽Belt idle wheel(10trough)

90011430016S六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600012886涨紧轮座Tension wheel seat

614070055机油泵垫片Oilpump gasket

61500070030双级机油泵Oil pump

612600070411六角法兰面承面带齿螺栓Hexagon Flange Bolt

90011430008六角法兰面承面带齿螺栓Hexagon Flange Bolt

90003802578S六角头螺栓Hexagon bolt

6140756中间齿轮轴Intermediate gear shaft

614070155密封圈Seal washer

612600070364机油泵中间齿轮组件Oil Pump Idle Gear Assembly

90003311410向心球轴承Centripetal ball bearing

90003934732带凸齿的孔用挡圈Circlip with Teeth for Hole

614070061机油泵中间齿轮Oil pump inter mediate gear

6140749中间隔圈Spacer ring

90013550021内六角圆柱头螺钉Inner hexagon screw

90013550022内六角圆柱头螺钉Inner hexagon screw

90003932023波形弹性垫圈Wave spiral washer

612600070349机油滤清器总成 Oil ilter assembly

612600070340支撑架Carriage

90003802411六角头螺栓Hexagon bolt

612600070336机油滤清器托架

612600070339支撑板Supporting plate

90003862428内六角圆柱头螺钉Inner hexagon screw

612600070375  机油滤座垫片 Oil filter seat gasket

61500070051机油滤清器底座组件Oil filter pedestal assembly

61000070005旋装式机油滤芯总成Rotary filter element assembly

614070078垫片Gasket

61500070082集滤器总成Strainer assembly

90003930271平垫圈Flat washer

90003802523S六角头螺栓Hexagon bolt

90011430021六角法兰面承面带齿螺栓Hexagon Flange Bolt

614070198吸油管总成Oil suction pipe assembly

614010084B机油冷却器盖垫片Oilcoolercovergasket

612600013135机油冷却器盖Oilcoolercover

90011410003六角法兰面螺栓HexagonFlangeBolt

612600112056支撑块Supportingplate

612600010465放水阀总成Valve

90011410009六角法兰面螺栓HexagonFlangeBolt

90017010003方头锥型螺塞

90003802419六角头螺栓Hexagonbolt

612600010626支撑块Supportingplate

90011410010六角法兰面螺栓HexagonFlangeBolt

612600040549中间接头

90003862419S内六角圆柱头螺钉Innerhexagonscrew

90003932023波形弹性垫圈Wavespiralwasher

61500010334机油冷却器Oilcooler

81400010032密封圈Sealwasher

612600080383六角头螺栓Hexagon bolt

61500080094A紧固压板Clamp plate

61560080305喷油器总成Injector assembly

609070080密封垫圈Seal washer

612600081954垫圈Washer

612600082202高压油管总成High pressure pipe assembly

612600082208第六缸高压油管总成High pressure pipe assembly(cylinder6)

612600082207第五缸高压油管总成High pressure pipe assembly(cylinder5)

612600082206第四缸高压油管总成High pressure pipe assembly(cylinder4)

612600082205第三缸高压油管总成High pressure pipe assembly(cylinder3)

612600082204第二缸高压油管总成High pressure pipe assembly(cylinder2)

612600082203第一缸高压油管总成High pressure pipe assembly(cylinder1)

61560080172支承架Support bracket

612600080580孔高压油管管夹总成2HolesHighPressureFuel Pipe Clamp Assembly

612600080576孔高压油管管夹总成3HolesHighPressureFuel Pipe Clamp Assembly

612600081883孔高压油管管夹总成6HolesHighPressureFuel Pipe Clamp Assembly

612600081882孔高压油管管夹总成4HolesHighPressureFuel Pipe Clamp Assembly

612600080708单孔高压油管管夹总成1HolesHighPressureFuel Pipe Clamp Assembly

612600082315支架Bracket

612600082135内六角圆柱头螺钉Inner hexagon screw

188250083自锁垫圈Washer

90003930261平垫圈Flat washer

612601080591喷油泵总成Injection pump assembly

90003813532S双头螺柱Stud

90003888452型全金属六角锁紧螺母Prevailing Torque Type All-metal Hexagon Nut,

612600082057喷油泵法兰Injection pump flange

612600080400密封圈Seal washer

612600082058喷油泵齿轮Injection pump gear

90011430034六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600082142喷油泵支架Injection pump bracket

90011430008六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600082094喷油泵托架Injection pump bracket

612600082141喷油泵支架Injection pump bracket

90003931122弹簧垫圈Spring washer

90003871305型六角螺母Hexagon nut(I)

612639000047空心螺栓Hollow bolt

612600082372润滑油管总成Oil pipe assembly

612600080246密封垫圈Seal washer

90003930271平垫圈Flat washer

90003962612空心螺栓Hollow bolt

61560080159空气管总成Air pipe assembly

612600050042密封垫圈Seal washer

90011430016六角法兰承面带齿螺栓Toothed bolt

612600081836燃油粗滤器支架Coarse fuel filter bracket

612600081495除水放心滤Fuel filter-water separator

90003962621空心螺栓Hollow bolt

612600080200密封垫圈Seal washer

90003932016波形弹性垫圈Wave spiral washer

90003802637六角头螺栓Hexagon bolt

90011430026六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600081333燃油滤清器Fuel filter

612600081933精滤器支架

612600061726六角法兰面承面带齿螺母Hexagon Flange Nut

612600081321燃油滤清器座Fuel Filter Seat

612600081335燃油滤清器滤芯Element of fuel filter

612600081327密封圈Seal washer

612600081322水杯总成Cup Assembly

612600082597滤清器座

612600081334燃油滤清器滤芯Element of fuel filter

612600081329喷油器回油管总成Oil return pipe assembly of injector

612600082229燃油管总成Fuel pipe assembly

90003559844卡套式管接头

90003559564卡套Cutting sleeve

90003559518卡套式管接头

612600080200密封垫圈Seal washer

612600082225燃油管总成Fuel pipe assembly

612600081880燃油管总成Fuel pipe assembly

612600080684夹子总成Clip assembly

90003962621空心螺栓Hollow bolt

612600080688复合密封垫圈Seal washer

61500080090空心螺栓Hollow bolt

13032540管夹总成Pipe Clamp Assembly

13032541管夹总成Pipe Clamp Assembly

90014350003弹簧垫圈Spring washer

90011260039六角头螺栓Hexagon bolt

90012630007型六角螺母Hexagon nut(I)

90014330007平垫圈Flat washer

612600090641拉紧块Tightening block

612600090705发电机Generator

90003932016波形弹性垫圈Wave spiral washer

615P00090003六角头螺栓Hexagon bolt

90011260010六角头螺栓Hexagon bolt

90003932025鞍形弹性垫圈Curved Spring Washer

612600090292压紧块Clamp block

90011350073六角头螺栓Hexagon bolt

90003935015平垫圈Flat washer

13039439拉紧螺栓Tightening bolt

612600061722六角法兰面承面带齿螺母Hexagon Flange Nut

90014230005波形弹性垫圈Wave spiral washer

612600061720六角法兰面承面带齿螺母Hexagon Flange Nut

612600090640发电机安装支架Generator Bracket

90014230002波形弹性垫圈Wave spiral washer

90011270006六角头螺栓全螺纹

90011430025六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600080275密封垫圈Seal washer

612600080802密封垫圈Seal washer

612600114520螺纹接头Screw joint

90017010001方头锥型螺塞

612600090033螺堵Plug

612600111183六角头螺塞Hexagon plug

90014400010密封垫圈Seal washer

61500110024进气管垫片Air inlet pipe gasket

612600113444进气管Intake manifold

612600114467六角法兰面螺栓Hexagon Flange Bolt

612600114858六角法兰面螺栓Hexagon Flange Bolt

612600114468六角法兰面螺栓Hexagon Flange Bolt

90003937283垫圈Washer

90003802415六角头螺栓Hexagon bolt

90003932023波形弹性垫圈Wave spiral washer

612600112391空气滤清器体Air filter

612600061720六角法兰面承面带齿螺母Hexagon Flange Nut

90011430001六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600113517支架板Bracket plate

90011430019六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600114987空气滤清器壳体Air Filter Housing

612600110540空气滤清器芯Air Filter Element

612600115971六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600112344排气管隔热罩Heat insulating cover of exhaust pipe

615T1110121右排气歧管Exhaust manifold(right)

615T1110122中间排气歧管Middle exhaust manifold

61560110242排气管垫片Exhaust pipe gasket

61260110162排气管密封环Seal washer of exhaust pipe

615T1110123前排气歧管Front exhaust manifold

612600116160排气管螺栓Exhaust pipe bolt

612600110282双头螺柱Stud

90003888470  2型全金属六角锁紧螺母Prevailing Torque Type All-metal Hexagon Nut,

612601111069废气涡轮增压器Exhaust turbo charger

01153347双头螺柱Stud

90003888451  2型全金属六角锁紧螺母Prevailing Torque Type All-metal Hexagon Nut,

615T1110056  增压器垫片Turbo charger washer

61260110048回油管法兰垫片Fuel return pipe flange washer

188250083自锁垫圈Washer

61460070014回油管螺栓Bolt for oil return pipe

612600070110增压器回油管组件Oil return pipe assembly of turbo charger

90003989301软管卡箍Hose clip

612600112716增压器回油软管耐低温Oil return hose of turbo charger (cold resistance)

612600070107回油弯管Fuel return elbow

612600114330增压器进油管Oil inlet pipe for turbo charger

612600114377六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600012796管夹总成Pipe Clamp Assembly

612600114275进油管垫片Fuel inlet pipe gasket

90003862427内六角圆柱头螺钉Inner hexagon screw

16126001137551气路连接胶管Air Connecting Rubber Pipe

2900039893152软管卡箍Hose clip

3900039893122软管卡箍Hose clip

461568C1200041气路连接胶管Air Connecting Rubber Pipe

56126001104351进气弯管Intake elbow

6900135500013内六角圆柱头螺钉Inner hexagon screw

7900038024322六角头螺栓Hexagon bolt

8900039320236波形弹性垫圈Wave spiral washer

9900038024421六角头螺栓Hexagon bolt

10900144000101密封垫圈Seal washer

11900039600051六角头螺塞Hexagon plug

12615P601100071垫片Gasket

139000387125211型六角螺母Hexagon nut(I)

90011430001六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600112966消声器Muffler

612600061720六角法兰面承面带齿螺母Hexagon Flange Nut

90003802419六角头螺栓Hexagon bolt

90003932023波形弹性垫圈Wave spiral washer

612600111087托架Bracket

612600061719六角法兰面承面带齿螺母Hexagon Flange Nut

90011430017六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600111501增压器垫片Turbo charger washer

612600110466膨胀管结合子组Expansion pipe sub assembly

615T1110071垫片Gasket

614150004密封垫Seal washer

612600150331油底壳总成Oil pan assembly

614150046油底壳托块Oil pan block

90011430019六角法兰面承面带齿螺栓Hexagon Flange Bolt

612600150390油底壳托块Oil pan block

90003960005六角头螺塞Hexagon plug

90003098029密封垫圈Seal washer

612600150459油底壳组件Oil pan assembly

612600150106密封垫圈Seal washer

612600150251磁性螺塞总成Magnetic screw plug assembly

612600012771发动机前支架Front bracket of engine

90003871344   1型六角螺母Hexagon nut(I)

90003931142弹簧垫圈Sprin

615T2110600排气管Exhaust manifold

612600113864一级空气粗滤器First Coarse Air Filter

g washer

90011270025六角头螺栓全螺纹

615T1020046飞轮螺栓Flywheel bolt

90003901453圆柱销Straight pin

90003901604圆柱销Straight pin

615T2110005冷却液连接胶管Coolant Connecting Rubber Pipe

90003989306软管卡箍Hose clip

612600090347  O型密封圈O shaped seal washer

612600010817后油封Rear oil seal

612600110995引射管Induction pipe

612600090828起动机Starter

612600112230排气尾管总成Exhaust tail pipe assembly

612600113864   1级空气粗滤器First Coarse Air Filter

612600090828起动机Starter
