23 4120002033 胶管 JB8406-B45*100 HOSE JB8406-B45*100 Y 1
24 4017000007 喉箍 JB8870-d60 CLAMP JB8870-d60 N 2
25 4015000203 垫圈 JB1002-24-T2 WASHER JB1002-24-T2 N 4
26 29030001031 变矩器至散热器油管 HOSE Y 2
27 29030001021 接头 CONNECTOR Y 2
28 4011000560 螺栓 GB16674-M12*25EpZn-8.8 BOLT GB16674-M12*25EpZn-8.8 N 4
29 4120000098 传动油散热器 LG02-YS1 OIL RADIATOR LG02-YS1 Y 1
30 4015000025 垫圈 GB93-10-65Mn WASHER GB93-10-65Mn N 8
31 4011000082 螺栓 GB5783-M10*25EpZn-8.8 BOLT GB5783-M10*25EpZn-8.8 N 8
32 29030009561 底板 PLATE Y 1

1 4110000725 油门踏板 ZY75-00 ACCELERATOR PEDAL ZY75-00 Y 1
2 4015000035 垫圈 GB93-6-65Mn WASHER GB93-6-65Mn N 5
3 4011000101 螺栓 GB5783-M6*20EpZn-8.8 BOLT GB5783-M6*20EpZn-8.8 N 5
4 4015000207 垫圈 GB97.1-6EpZn-300HV WASHER GB97.1-6EpZn-300HV N 2
5 4013000028 螺母 GB6170-M6EpZn-8 NUT GB6170-M6EpZn-8 N 2

1 4110000507 滤清器 QF60M33G-1 FILTER QF60M33G-1 Y 1
2 4011000107 螺栓 GB5783-M8*30EpZn-8.8 BOLT GB5783-M8*30EpZn-8.8 N 4
3 4015000036 垫圈 GB93-8-65Mn WASHER GB93-8-65Mn N 4
4 29040001021 变速箱至滤清器油管 HOSE Y 1
5 29040001031 滤清器至变速箱油管 HOSE Y 1
6 4110000483 变矩器 YJSW315-8A TORQUE CONVERTER YJSW315-8A Y 1
7 4011000207 螺栓 GB5783-M12*45EpZn-8.8 BOLT GB5783-M12*45EpZn-8.8 N 12
8 4015000026 垫圈 GB93-12-65Mn WASHER GB93-12-65Mn N 12
9 29040000041 密封垫 SEAL WASHER Y 1
10 4011000479 螺栓 GB16674-M12*30EpZn-8.8 BOLT GB16674-M12*30EpZn-8.8 N 2
11 29040001041 支承架 BRACKET Y 1
12 4120000125 接头体 GB3733.2-G28EpZn-35 JOINT BODY GB3733.2-G28EpZn-35 Y 2
13 4030000013 O 形圈 GB1235-32*3.1 O-RING GB1235-32*3.1 Y 2

1 4110000011081 导轮座 YB315Z5-13A STATOR SEAT YB315Z5-13A Y 1
2 4110000011082 密封环 YB315Z5-33 SEAL RING YB315Z5-33 Y 1
3 4110000011083 密封环 YB315Z5-12 SEAL RING YB315Z5-12 Y 1
4 4110000011084 停用 – 弹性圈 YB315Z5-25 SPRING WASHER YB315Z5-25 Y 1
5 4110000011085 壳体 YB315Z5-08A HOUSING YB315Z5-08A Y 1
6 4110000011086 螺栓 M8*16 01010-50816 BOLT M8*16 01010-50816 Y 8
7 4110000011087 垫圈 801602-10825 WASHER 801602-10825 Y 4
8 4110000011088 垫板 YB315Z5-06A FILLER YB315Z5-06A Y 1
9 4110000011089 胶垫 YB315Z5-07 SPACER YB315Z5-07 Y 1
10 4110000483001 齿轮 YJSW315-8A-00004 GEAR YJSW315-8A-00004 Y 1
11 4021000076 滚动轴承 GB276-6017 BEARING GB276-6017 Y 2
12 4110000011091 螺栓 M8*35 01010-50835 BOLT M8*35 01010-50835 Y 38
13 4110000518001 泵轮 YJSW315-8A-00003 IMPELLER YJSW315-8A-00003 Y 1
14 4110000518002 螺母 01580-00806 M8 NUT 01580-00806 M8 Y 24
15 4110000011121 调整垫 YB315Z5-35 ADJUSTING SPACER YB315Z5-35 Y 1
16 4110000011094 压紧垫片 YB315Z5-22A COMPRESSING SHIM YB315Z5-22A N 1
17 4110000518003 导轮 YJSW315-8A-00002 STATOR YJSW315-8A-00002 Y 1
18 4015000208 挡圈 GB894.1-85-65Mn RETAINER RING GB894.1-85-65Mn N 1
19 4110000518005 Ⅰ涡轮 YJSW315-8A-10001 FIRST-STAGETURNINE YJSW315-8A-10001 N 1
20 4110000518006 Ⅱ涡轮组 YJSW315-8A-11000 SECOND-STAGE TURBINE YJSW315-8A-11000 N 1
21 4110000011096 调整垫 YB315Z5-30/31/32 ADJUSTING SHIM YB315Z5-30/31/32 Y 1
22 4110000011125 挡圈 52 YB315Z5.1-5 RETAINER RING 52 YB315Z5.1-5 N 1

23 4021000155 轴承 6013 BEARING 6013 N 1
24 4011000663 螺栓 GB21-M10*25EpZn-8.8 BOLT GB21-M10*25EpZn-8.8 N 9
25 4110000011097 垫圈 10 01602-11030 WASHER 10 01602-11030 Y 2
26 4110000518008 管接头 YB315Z5-14S FITTING YB315Z5-14S Y 2
27 4110000011128 垫圈 30 07003-03036 WASHER 07003-03036 Y 2
28 4110000011100 阀盖 YB315Z5-17A VALVE CAP YB315Z5-17A Y 1
29 4110000011101 弹簧 YB315Z5-18A SPRING YB315Z5-18A Y 1
30 4110000011102 调压垫 YB315Z5-16.21 ADJUSTING SHIM YB315Z5-16.21 N 3
31 4110000011103 阀杆 YB315Z5-26A VALVE ROD YB315Z5-26A Y 2
32 4110000011104 螺塞 YB315Z5-15L PLUG YB315Z5-15L Y 1
33 4110000011105 压板 YB315Z5-19A PRESS PLATE YB315Z5-19A N 1
34 4110000011106 弹簧 YB315Z5-20 SPRING YB315Z5-20 Y 1
35 4110000011108 垫圈 12 01602-11236 WASHER 01602-11236 12 Y 1
36 4110000011109 螺栓 M12*45 01010-51245 BOLT M12*45 01010-51245 Y 1
37 4110000011129 管接头 YB315Z5-24K PIPE JOINT YB315Z5-24K Y 1
38 4019000063 铆钉 GB869-8*15 RIVET GB869-8*15 N 1
39 4110000011131 涡轮毂 YB315Z5.1-1 TURBINE WHEEL YB315Z5.1-1 N 1
40 4110000518011 涡轮罩 YJSW315-8A-12001 TURBINE COVER YJSW315-8A-12001 N 1
41 4021000018 滚动轴承 GB276-6210 BEARING GB276-6210 Y 1
42 4110000011134 停用 – 销 YB315Z5.1-4A PIN YB315Z5.1-4A N 8
43 4030000712 O 形圈 GB3452.1-365*3.55G O-RING GB3452.1-365*3.55G Y 1
44 4110000518013 罩轮 YJSW315-8A-00001 WHEEL SHELL YJSW315-8A-00001 Y 1

45 4110000011113 调整垫 YB315Z5-34 ADJUSTING SHIM YB315Z5-34 Y 1
46 4110000011116 圆垫板 YB315Z5-04 RING PALLET YB315Z5-04 Y 1
47 4110000011118 衬垫 YB315Z5-05 MAT YB315Z5-05 Y 1
48 4110000011117 螺栓 M12*30 01010-51230 BOLT M12*30 01010-51230 Y 6
49 4110000011115 弹性板 YJSW315-20001 ELASTIC PLATE Y 2
50 4110000011114 弹性板总成 YJSW315-20000 ELASTIC PLATE ASSEMBLY YJSW315-20000 Y 1
51 4110000518015 涡轮组件 YJSW315-8A-10000 TURBINE SUBASSEMBLY YJSW315-8A-10000 Y 1
