1 Rice tire 14.9-30 GB/T2979-82 2 1 Rice tire 16.9-34 GB 2979-91 2
2 Rim and spoke unit（W12-30） SZ700.34.020 2 2 Rim and spoke unit
（W15-34）
880804902/1.49 2
2.1 Rim and bracket weldment
(W12-30)
SZ700.34.021 2 2.1 Welded rim unit （W15-34） 880804903/1.49 2
2.2 Nut M16×1.5 GB/T6171-86 16 2.2 Bolt, rim & spoke 5131725/1.49.541A 16
2.3 Washer, spoke 16.6×33×3.5 4986961/1.49.440 16 2.3 Washer, spoke 16.6×33×3.5 4986961/1.49.440 16
2.4 Spoke, traction wheel 880804910/1.49 2 2.4 Nut M16×1.5 GB/T6171-2000 16
2.5 Bolt, rim & spoke
M16×1.5×125
5131725/1.49.541 16 2.5 Spoke, traction wheel 880804906/1.49 2
3 Nut M18×1.5 GB/T6171-86 16 3 Nut M18×1.5 GB/T6171-2000 16
4 Washer 44011091/1.49.540 16 4 Washer 44011091/1.49.540 16

No. Part Name Part No. Qty. No. Part Name Part No. Qty.
1 Washer 12 GB/T93-1987 15 22 Dowel pin 15 10839910/12507 2
3 Bolt M16×110 GB/T5782-2000 2 23 Shield (LWR), cover
(UPR), transmission case
5147242/1.21.014 1
4 Bolt M14×75-Zn.D GB/T70.1-2000 2 24 Washer 6 GB/T93-1987 8
6 Nut M12-Zn.D GB/T6170-2000 3 25 Bolt M6×12 GB/T70-85 8
7 Stud
AGM12-M12×55-8.8-Zn.D
GB/T899–1988 3 26 Plug 25 10159004/14520 4
8 Bolt M14×75-Zn.D GB/T5782-2000 8 27 Cover (UPR), transmission
case
5132478SZ/1.21.008 1
9 Washer 14 GB/T93-1987 10 28 Elbow connection, breather
plug
885139648/1.21.072 1
10 Housing, reducer LX954.37.101 1 29 Clamp (Φ8～Φ19mm) JK-000 2
11 Washer 16 GB/T93-197 2 30 Breather hose 5139650/1.21.074 1
12 Washer 22 JB/T982-1977 2 31 Bolt M10×1.25×70 GB/T5785-2000 2
13 Plug M22×1.5 10305171/14530 2 32 Bolt M10×1.25×35 GB/T5785-2000 6
14 Bushing, shaft, release fork,
main clutch
5133142/1.21.031 2 33
Breather plug assembly
5141476/1.21.076A 2
15 Inspection cover, clutch LY1054.37.106 1 34 Dowel pin 15×22 5119529/1.21.071 2
16 Pin 6.3×32 GB/T91-2000 1 35 Housing, transmission case SZ804.37.117 1
17 Washer 8 GB/T93-1987 7 36 Dowel pin 5110200/1.21.065 4
18 Bolt M8×16 GB/T5783-2000 4 37 Dowel pin B12×18 GB/T119-86 4
19 Screw M10×1.25×20 13305311/10532 1 38 Connection, transmission
case & reducer screw
M12×1.25×40
SZ804.37.512 12
20 Screw M12×1.25×40,
connecting transmission case
with reducer
SZ804.37.512 12 39 Elbow connection
weldment, breather plug
SZ804.37.040 1
21 Magnetic drain plug unit 885118991/1.21.030A 2 40 Elbow connection
weldment, breather plug
SZ804.37.403 1

1 Washer 12 GB/T93-1987 15 22 Dowel pin 15 10839910/12507 2
3 Bolt M16×110 GB/T5782-2000 2 23 Shield (LWR), cover
(UPR), transmission case
5147242/1.21.014 1
4 Bolt M14×75-Zn.D GB/T70.1-2000 2 24 Washer 6 GB/T93-1987 8
6 Nut M12-Zn.D GB/T6170-2000 3 25 Bolt M6×12 GB/T70-85 8
7 Stud
AGM12-M12×55-8.8-Zn.D
GB/T899–1988 3 26 Plug 25 10159004/14520 4
8 Bolt M14×75-Zn.D GB/T5782-2000 8 27 Cover (UPR), transmission
case
5132478SZ/1.21.008 1
9 Washer 14 GB/T93-1987 10 28 Elbow connection, breather
plug
885139648/1.21.072 1
10 Housing, reducer LX954.37.101 1 29 Clamp (Φ8～Φ19mm) JK-000 2
11 Washer 16 GB/T93-197 2 30 Breather hose 5139650/1.21.074 1
12 Washer 22 JB/T982-1977 2 31 Bolt M10×1.25×70 GB/T5785-2000 2
13 Plug M22×1.5 10305171/14530 2 32 Bolt M10×1.25×35 GB/T5785-2000 6
14 Bushing, shaft, release fork,
main clutch
5133142/1.21.031 2 33
Breather plug assembly
5141476/1.21.076A 2
15 Inspection cover, clutch LY1054.37.106 1 34 Dowel pin 15×22 5119529/1.21.071 2
16 Pin 6.3×32 GB/T91-2000 1 35 Housing, transmission case SZ804.37B.531 1
17 Washer 8 GB/T93-1987 7 36 Dowel pin 5110200/1.21.065 4
18 Bolt M8×16 GB/T5783-2000 4 37 Dowel pin B12×18 GB/T119-86 4
19 Screw M10×1.25×20 13305311/10532 1 38 Connection, transmission
case & reducer screw
M12×1.25×40
SZ804.37.512 12
20 Screw M12×1.25×40,
connecting transmission case
with reducer
SZ804.37.512 12 39 Elbow connection
weldment, breather plug
SZ804.37.040 1
21 Magnetic drain plug unit 885118991/1.21.030A 2 40 Elbow connection
weldment, breather plug
SZ804.37.403 1

1 Washer 12 GB/T93-1987 15 22 Dowel pin 15 10839910/12507 2
3 Bolt M16×110 GB/T5782-2000 2 23 Shield (LWR), cover
(UPR), transmission case
5147242/1.21.014 1
4 Bolt M14×75-Zn.D GB/T70.1-2000 2 24 Washer 6 GB/T93-1987 8
6 Nut M12-Zn.D GB/T6170-2000 3 25 Bolt M6×12 GB/T70-85 8
7 Stud
AGM12-M12×55-8.8-Zn.D
GB/T899–1988 3 26 Plug 25 10159004/14520 4
8 Bolt M14×75-Zn.D GB/T5782-2000 8 27 Cover (UPR), transmission
case
5132478SZ/1.21.008 1
9 Washer 14 GB/T93-1987 10 28 Elbow connection, breather
plug
885139648/1.21.072 1
10 Housing, reducer LX954.37.101 1 29 Clamp (Φ8～Φ19mm) JK-000 2
11 Washer 16 GB/T93-197 2 30 Breather hose 5139650/1.21.074 1
12 Washer 22 JB/T982-1977 2 31 Bolt M10×1.25×70 GB/T5785-2000 2
13 Plug M22×1.5 10305171/14530 2 32 Bolt M10×1.25×35 GB/T5785-2000 6
14 Bushing, shaft, release fork,
main clutch
5133142/1.21.031 2 33
Breather plug assembly
5141476/1.21.076A 2
15 Inspection cover, clutch LY1054.37.106 1 34 Dowel pin 15×22 5119529/1.21.071 2
16 Pin 6.3×32 GB/T91-2000 1 35 Housing, transmission case SZ804.37B.530 1
17 Washer 8 GB/T93-1987 7 36 Dowel pin 5110200/1.21.065 4
18 Bolt M8×16 GB/T5783-2000 4 37 Dowel pin B12×18 GB/T119-86 4
19 Screw M10×1.25×20 13305311/10532 1 38 Connection, transmission
case & reducer screw
M12×1.25×40
SZ804.37.512 12
20 Screw M12×1.25×40,
connecting transmission case
with reducer
SZ804.37.512 12 39 Elbow connection
weldment, breather plug
SZ804.37.040 1
21 Magnetic drain plug unit 885118991/1.21.030A 2 40 Elbow connection
weldment, breather plug
SZ804.37.403 1

1 Washer 12 GB/T93-1987 15 22 Dowel pin 15 10839910/12507 2
3 Bolt M16×110 GB/T5782-2000 2 23 Shield (LWR), cover
(UPR), transmission case
5147242/1.21.014 1
4 Bolt M14×75-Zn.D GB/T70.1-2000 2 24 Washer 6 GB/T93-1987 8
6 Nut M12-Zn.D GB/T6170-2000 3 25 Bolt M6×12 GB/T70-85 8
7 Stud
AGM12-M12×55-8.8-Zn.D
GB/T899–1988 3 26 Plug 25 10159004/14520 4
8 Bolt M14×75-Zn.D GB/T5782-2000 8 27 Cover (UPR), transmission
case
SZ804.37B.506 1
9 Washer 14 GB/T93-1987 10 28 Elbow connection, breather
plug
885139648/1.21.072 1
10 Housing, reducer LY1054.37.101 1 29 Clamp (Φ8～Φ19mm) JK-000 2
11 Washer 16 GB/T93-197 2 30 Breather hose 5139650/1.21.074 1
12 Washer 22 JB/T982-1977 2 31 Bolt M10×1.25×70 GB/T5785-2000 2
13 Plug M22×1.5 10305171/14530 2 32 Bolt M10×1.25×35 GB/T5785-2000 6
14 Bushing, shaft, release fork,
main clutch
5133142/1.21.031 2 33
Breather plug assembly
5141476/1.21.076A 2
15 Inspection cover, clutch LY1054.37.106 1 34 Dowel pin 15×22 5119529/1.21.071 2
16 Pin 6.3×32 GB/T91-2000 1 35 Housing, transmission case SZ804.37B.508 1
17 Washer 8 GB/T93-1987 7 36 Dowel pin 5110200/1.21.065 4
18 Bolt M8×16 GB/T5783-2000 4 37 Dowel pin B12×18 GB/T119-86 4
19 Screw M10×1.25×20 13305311/10532 1 38 Connection, transmission
case & reducer screw
M12×1.25×40
SZ804.37.512 12
20 Screw M12×1.25×40,
connecting transmission case
with reducer
SZ804.37.512 12 39 Elbow connection
weldment, breather plug
SZ804.37.040 1
21 Magnetic drain plug unit 885118991/1.21.030A 2 40 Elbow connection
weldment, breather plug
SZ804.37.403 1
