1 01119243 2 空心螺栓 Hollow bolt
2 01151548 8 六角头螺栓 Hexagon bolt
3 13021359 6 六角头螺栓 Hexagon bolt
4 12151281 6 弹簧垫圈 Spring washer
5 01178366 8 弹簧垫圈 Spring washer
6 612600080200 4 密封垫圈 Seal washer
1 13060619 1 一级空气粗滤器 First Coarse Air Filter
2 13023178 1 废气引射管总成 Exhaust Gas Injecting Pipe Assembly
3 13030243 1 左后支架 Rear bracket (left)
4 13022731 1 发动机前左支架 Front bracket of engine (left)
5 13022732 1 发动机前右支架 Frant bracket of engine (right)
6 13030244 1 右后支架 Rear bracket (right)
1 13020212 2 吊环螺钉 Eye screw
2 13054119 12 气缸盖螺栓 Cylinder head bolt
3 13054252 4 气缸盖螺栓 Cylinder head bolt
4 13054251 8 气缸盖螺栓 Cylinder head bolt
5 01152414 2 六角头螺栓 Hexagon bolt
6 13024222 2 弹簧垫圈 Spring washer
7 13052790 1 油门拉线支架 Throttle wire bracket
8 01151599 3 双头螺柱 Stud
9 13033415 2 圆柱销 Straight pin
10 01105156 1 圆柱销 Straight pin
11 01118707 1 密封垫圈 Seal washer
12 01151453 1 六角头螺塞 Hexagon plug
13 01115413 7 弹性圆柱销 Spring dowel pin
14 13057039 1 组合密封垫圈 Unit seal washer
15 01118952 1 六角头螺塞 Hexagon plug
16 13052432 1 机体分总成 Cylinder block subassembly
17 13022330 1 轴 Shaft
1 13056682 6 气缸套 Cylinder liner
2 01153804 12 O型密封圈 O shaped seal washer
3 01153805 12 O型密封圈 O shaped seal washer
4 01152717 5 碗形塞 Corehole plug
5 12159599 1 凸轮轴衬套 Camshaft bushing
6 12151365 8 塞子 Plug
7 12273515 2 塞子 Plug
8 13032911 5 凸轮轴衬套 Camshaft bushing
9 13032912 1 凸轮轴衬套 Camshaft bushing
10 90003813532S 4 双头螺柱 Stud
11 13037380 10 主轴承螺栓 Main bearing bolt
12 12190135 1 止推轴承盖 粗加工 Thrust bearing cover(roughcast machining)
13 13037381 4 主轴承螺栓 Main bearing bolt
14 12188652 6 主轴承盖 粗加工 Main bearing cover(roughcast machining)
15 13039690 1 碗形塞 Corehole plug
16 12160129 1 固定板 Fixed plate
17 01177981 1 弹簧垫圈 Spring washer
18 01151498 1 内六角圆柱头螺钉 Inner hexagon screw
19 01153869 1 O型密封圈 O shaped seal washer
20 12160117 1 焊接弯管 Weld elbow
21 13039669 1 圆柱销 Straight pin
22 01153348 1 双头螺柱 Stud
23 13039535 1 机体 Cylinder block
24 12273557 2 塞子 Plug
25 13057039 1 组合密封垫圈 Unit seal washer
26 01118952 1 六角头螺塞 Hexagon plug
27 13031278 1 套管 Sleeve
