1 J3601-1303003B 调温器座 Thermostat seat 1
2 Q67645 环箍 45 Loop hoop 45 2
3 J3601-1306005A 回水胶管 Water return rubber pipe 1
4 A3000-1303012 节温器盖垫片 Thermostat cover spacer 1 易损件 EWP
5 630-1306010B 蜡式调温器 Wax thermostat 1
6 A3540-1306001 节温器盖 Thermostat cover 1
7 291-1306028A 放气管接头 Air release pipe joint 1
8 Q150B0820 螺栓 M8×20 Bolt M8×20 5
9 Q40308 垫圈 8 Lock Washer 8 5
10 6105Q-1303013 节温器座垫片 Thermostat pedestal gasket 1 易损件 EWP
11 177-1306023C 螺塞 Screw plug 1
12 Q/YC149-36 复合式密封垫圈 36 Compound seal washer 36 1 易损件 EWP

1 J3601-1307100H 水泵 Water pump 1
2 Q150B0850TF2 螺栓 M8×50 Bolt M8×50 2
3 Q40308 垫圈 8 Washer 8 4
4 Q40108 垫圈 8 Washer 8 4
5 Q150B0832TF2 螺栓 M8×32 Bolt M8×32 1
6 3430-1307011B 水泵衬垫 Water pump lining washer 1 易损件 EWP
7 Q/YC149-14 复合式密封垫圈 14 Compound seal washer 14 1
8 Q/YC198-14 螺塞 M14×1.5 Screw plug M14×1.5 1
9 Q/YC147.1-71 环箍 71 Loop hoop 71 2
10 A3000-1307005 胶管 Rubber pipe 1
11 A4200-1119030 中冷器回水接头 1
12 J1A15-1307250 水泵进水管组件 Water inlet pipe subassembly 1
13 E0216-1306013 过渡塞 1
14 Q150B0820 螺栓 M8X20 Bolt M8X20 1
15 Q40308 垫圈 8 Washer 8 1
16 Q40208 垫圈 8 Washer 8 1
17 151-1307017A 暖风回水接头 1
18 Q150B1025 螺栓 M10X25 Bolt M10X25 1
19 A30-1307032 夹箍 Clamp 2
20 Q40110 垫圈 10 Washer 10 1
21 Q40310 垫圈 10 Washer 10 1
22 Q340B10 螺母 M10 Nut M10 1
23 A4136-1307050 皮带 SPA1365 Belt SPA1365 2 易损件 EWP
24 Q150B0865TF2 螺栓 M8×65 Bolt M8×65 1
