2 Q5003220 销 3.2X20 Pin 3.2X20 1
3 150-1305015 操纵杆 Holding rod 1

1 J3601-1303003B 调温器座 Thermostat seat 1
2 A3000-1303012 节温器盖垫片 Thermostat seat cover gasket 1 易损件 EWP
3 630-1306010B 蜡式调温器 Thermostat 1
4 A3540-1306001 节温器盖 Thermostat cover 1
5 291-1306028A 放气管接头 Air Bleeder pipe joint 1
6 Q150B0820 螺栓 M8X20 Bolt M8X20 5
7 Q40308 垫圈 8 Washer 8 5
8 A7001-1303016 回水胶管 Water return plastic pipe 1
9 Q67645 环箍 45 Hoop 45 2
10 6105Q-1303013 节温器座垫片 Thermostat pedestal gasket 1 易损件 EWP
11 Q/YC149-36 复合式密封垫圈 36 Compound Seal washer 36 1 易损件 EWP
12 177-1306023C 螺塞 Screw plug 1

1 A3206-1307100B 水泵 Water pump 1
2 A3100-1307004B 水泵垫片(II) Water pump gasket(II) 1 易损件 EWP
3 A3000-1307005 胶管 Rubber pipe 1
4 Q67676 环箍 76 Hoop 76 2
5 A1116-1307250 水泵进水管焊接件 Water inlet pipe weldment 1
6 B3206-1303028 暖风进水接头 Warm air water inlet joint 2
7 L3001-1307202A 支撑板 Supporting plate 1
8 Q1841022 螺栓 M10X22 Bolt M10X22 2
9 Q1841016 螺栓 M10X16 Bolt M10X16 1
10 Q150B1075TF2 螺栓 M10X75 Bolt M10X75 3
11 Q40310 垫圈 10 Washer 10 5
12 Q40110 垫圈 10 Washer 10 5
13 Q150B1065TF2 螺栓 M10X65 Bolt M10X65 2
14 A3206-1307002A 汽车多楔带 Poly V-belt 1

1 A1116-1308150 风扇组件 Fan subassembly 1
2 M36B1-1308200 风扇减振器部件 Fan damper part 1
3 A3206-1308300C 风扇轴部件 Fan shaft part 1
4 Q1841035TF2 螺栓 M10X35 Bolt M10X35 3
5 Q1841225TF2 螺栓 M12X25 Bolt M12X25 4
6 Q1841020TF2 螺栓 M10X20 Bolt M10X20 4
