WG1642230012 1 B,BR,C,CR Left wheel fender
WG1641230020 1 A,AR Left wheel fender
WG1642230013 1 B,C,BR,CR Right wheel fender
WG1641230021 1 A,AR Right wheel fender
Q150B0620 14 Screw
Q40106 14 Washer
Q40306 14 Spring washer
Q340B06 14 Nut
WG1642230018 1 Step left
WG1642230019 1 Step right
Q2540830 8 Screw
AZ9725930049 4 Bracket for step bow
WG9725930017 4 B,BR,C,CR Bracket for step bow
WG1641240011 1 Right step bow
WG1641240012 1 Left step bow
WG1642240030 Left step bow bottom
WG1642240031 Right step bow bottom
Q150B0825 8 Screw
Q340B08 8 Nut
Q40308 8 Spring washer
WG1642230003 1 Left rear wheel fender
WG1642230004 1 Right rear wheel fender
WG1642230005 4 Aux.plate for wheel fender
AZ1642230008 18 Washer
AZ1642230007 2 Pad for rear wheel fender
Q2713516 18 Screw
Q150B0860 8 Screw
Q150B0620 8 Screw
Q340B08 8 Nut
Q340B06 8 Nut
Q40308 8 Spring washer
Q40306 8 Spring washer
Q40106 8 Washer
WG1642240032 1 Bottom step left
WG1642240033 1 Bottom step right
Q2540830 8 Screw
Q40308 8 Spring washer
Q340B08 8 Nut
WG9719930315 1 Bracket for left rear mudguard
WG9731930010 1 8×4 Bracket for left rear mudguard
WG9731930015 1 8×4 Bracket for right rear mudguard
WG9719930313 1 Bracket for right rear mudguard
WG9719930321 2 Plate
WG9731930014 2 8×4 Plate
Q151B1445 2 Screw
190003888468 2 Nut
WG1641230028 1 A,AR Rear cover
WG1641230030 1 A,AR Bracket for rear cover
Q2714816 3 A,AR Screw
Q150B0620 3 A,AR Screw
Q40206 8 A,AR Washer
Q40306 8 A,AR Spring washer
Q340B06 4 A,AR Nut
Q40204 3 A,AR Washer
WG1641230025 1 Left mudguard
WG1641230026 1 Right mudguard
AZ1641230027 2 Strip for mudguard
