| Part Number | 452061-5002S |
| Previous Version | 452061-0002, 452061-2 |
| OE Number | 2674A061, 2674A061P |
| Description | Agricultural Tractor MF292 T250-02 |
| CHRA | 443854-0088 (443854-5088S) $500.00 |
| Turbo Model | T250-02 |
| Engine Model | 1004-4TLR, P4000T |
| KW | 88 |
| Fuel | Diesel |
| Displacement | 4.0L, 4000 ccm, 4 Cylinders |
| Angle α (compressor housing) | 0� |
| Angle β (turbine housing) | 205� |
| Bearing Housing | 435349-0016 (Oil Cooled) $65.00 |
| Turbine Wheel | 435257-0002 (431126-0001, 431126-0002, 432620-0002, 435257-0001, 435737-0005, 435922-0001)(Ind. 52.7 mm, Exd. 41.7 mm, Trm 62, 11 Blades) $110.80 NEW IN STOCK |
| Comp. Wheel | 446335-0009 (446335-0007)(Ind. 38.08 mm, Exd. 53.97 mm, Trm 45, 6+6(10) Blades, Superback) $60.00 NEW IN STOCK |
| Back plate | 430735-0001 (430612-0003)(1100025300) $16.84 NEW IN STOCK |
| Heat shield Number | 443594-0001 (1100025341) $13.84 NEW IN STOCK |
| Repair Kit | 709143-0001 (200423-0000, 707903-0002)(1100025761) $69.00 NEW IN STOCK |
| Turbine Housing | 434139-0013 |
| Compressor Cover | 413976-0011 |
| Turbine Housing AR | 0.49 |
| Gasket (turbine inlet) | 409039-0001 (210190, 210190-0000, 312617, 132044)(Stainless Steel, Single Port) $13.20 |
| Gasket (turbine outlet) | 210225 (Stainless Steel) |
| Gasket (oil outlet) | 413709-0001 (Paper) $5.11 |
| Replaced by | 711857-5002S, 711857-0002 |
| Manufacturer | Honeywell-Garrett |
Note: 62 trim turbine wheel in 79 trim housing = 3mm wheel clearance. This is correct! It is also possible to use 711857-5002S by changing housing orientations.
1993- Massey Ferguson Agricultural Tractor MF292 with 1004 TLR Engine
Perkins Agricultural with 1004 TLR Engine
