| Part Number | 762785-5004S |
| Previous Version | 762785-0001, 762785-0002, 762785-0003, 762785-5004S, 762785-5003S |
| OE number | 8200543466B, 8200766344, 8200637628, 820091077A, 7701477300, 7711368774 |
| Year | 2006-08 |
| Description | Traffic, Commercial Vehicle |
| CHRA | 433289-0419 (433289-0380) (1102015955) $250.00 NEW IN STOCK, MADE IN USA |
| Turbo Model | GT1549S |
| Engine | M1DVU, M1D VU Euro 4, M9R780 |
| Displacement | 2.0L, 2000 ccm, 4 Cylinders |
| KW | 84/90 HP |
| RPM Max | 4000 |
| Fuel | Diesel |
| Angle α (compressor housing) | 13� |
| Angle β (turbine housing) | 0� |
| Bearing Housing | 435911-0002/713782-0003 (1102015453) $55.00 NEW IN STOCK |
| Turbine Wheel | 434712-0034 (Ind. 42.1 mm, Exd. 34.3 mm, 12 Blades) (1102015433) NEW IN STOCK |
| Comp. Wheel | 784361-0003 (Ind. 42. mm, Exd. 35.6 mm, 6+6 Blades) (1102017402) NEW IN STOCK |
| Back plate | 703682-0220 (1102015319) NEW IN STOCK |
| Heat shield Number | 434302-0001 (1102015343) $11.52 NEW IN STOCK |
| Repair Kit | 732252-0001 (1102015756) $66.80 NEW IN STOCK |
| Turbine Housing | 700866-0013 |
| Compressor Cover | 752187-0017 |
| Actuator | 703785-0017 |
| Settings Waste gate (pressure) | 0.120-0.400 bar |
| Settings Waste gate (lift shaft) | 1.0-4.0 mm/9.5-11.5 mm |
| Gasket (turbine inlet) | 210661 |
| Gasket (turbine outlet) | 210880 |
| Washer (oil inlet fitting) | 435197-0005 |
| Gasket (oil outlet) | 210243 $4.50 |
| Manufacturer | Honeywell-Garrett |
2006-08 Renault Commercial Traffic with M1D VU Euro 4 Engine
2006- Opel Vivaro 2.0L CDTI with M9R780 Engine
