| Part Number | 716665-5002S |
| Previous Version | 716665-0001, 716665-0002, 716665-9003S, 716665-2 |
| OE number | 55191934, 46793334, 71783873, 71785259, 71785260, 71783874 |
| Year | 2003-04 |
| Description | Alfa Romeo 147/156 JTD, Lancia LYBRA JTD, Fiat STILO JTD |
| CHRA | 703890-0043 |
| Turbo Model | GT1749V |
| Engine | M724.19 16Ventil, M.724.19 |
| Displacement | 1.9L, 1900 ccm |
| KW | 110/140 HP |
| RPM Max | 4000 |
| Fuel | Diesel |
| Angle a (compressor housing) | 0� |
| Angle � (turbine housing) | 145.5� |
| Bearing housing | 722282-0057 |
| Turbine Wheel | 434533-0018 |
| Comp. Wheel | 702489-0001 |
| Back plate | 700593-0003 |
| Heat Shield | 433112-0001 |
| Repair Kit | N/A |
| Turbine Housing A/R | VNT2 |
| Settings Waste gate (pressure) | 0.264-0.269 bar |
| Settings Waste gate (lifting rod) | 3.5-6.0 mm |
| Gasket oil inlet | 210243 |
| Gasket (turbine inlet) | 210385 |
| Manufacturer | Honeywell-Garrett |
22003-04 Alfa Romeo 147 JTD with M.724.19 Engine
2003-04 Alfa Romeo 156 JTD 140 with M.724.19 Engine
2003-04 Fiat Stilo JTD 140 with M.724.19 Engine
2004- Lancia Lybra JTD 140 with M.724.19 Engine
