| Part Number | 716626-5001S |
| Previous Version | 716626-0001, 716626-1 |
| OE number | 46799071 |
| Year | 2001-03 |
| Description | Lancia, Fiat Lybra 2.4 JTD |
| CHRA | 703891-0035 |
| Turbo Model | GT225, GT2256V |
| Engine | M722.24, M722.24 Euro 3, 839A6.000 |
| Engine Manufacturer | Fiat |
| Displacement | 2.4L, 2400 ccm, 5 Cylinders |
| KW | 103/250 HP |
| RPM Max | 4000 |
| Fuel | Diesel |
| Angle α (compressor housing) | 172� |
| Angle β (turbine housing) | 35� |
| Bearing Housing | 722282-0056 |
| Turbine Wheel | 434882-0012 |
| Comp. Wheel | 707747-0002 |
| Back plate | 701335-0010 |
| Heat shield Number | 410366-0003 $32.42 NEW IN STOCK |
| Nozzle Ring Assembly | 717506-0006 |
| Repair Kit | 732252-0001 NEW IN STOCK |
| Turbine Housing | 441282-0031/441041-0002 |
| Compressor Cover | 413618-0001 |
| Turbine Housing AR | 1.40 |
| Settings Wastegate adjustment (pressure) | 0.264-0.269 bar |
| Settings Wastegate (lift shaft) | 3.5-6.0 mm |
| Gasket (oil outlet) | 210243 |
| Gasket (turbine outlet) | 210227 |
| Gasket (turbine inlet) | 210276 |
| Manufacturer | Honeywell-Garrett |
2001- Fiat Lybra with M722.24 Engine
2001- Lancia LYBRA 2.4L JTD with M722.24 Engine
2001- Lancia Lybra JTD 2.4L D with M722.24 Engine
2001-03 Lancia Lybra JTD 2.4L D with M722.24 Engine
