| Part Number | 466384-5003S |
| Previous Version | 466384-0003, 466384-3 |
| OE Number | 7647949, 7574229 |
| Year | 1986-91 |
| Description | Fiat Croma IE |
| CHRA | 409853-0033 (409853-5051S, 409853-0051, 409853-0041, 409853-0019, 409853-0039) $325.00 NEW IN STOCK, MADE IN USA |
| Turbo Model | TB0338 |
| Engine Model | M.601.HT.20.0 |
| Engine Manufacturer | Fiat |
| KW | 110/114 |
| Fuel | Gasoline |
| Displacement | 2.0L, 1995 ccm, 4 Cylinders |
| Angle α (compressor housing) | 0� |
| Angle β (turbine housing) | 195� |
| Bearing Housing | 430027-0025 (312379, 407285-0027, 407285-0038, 430027-0022, 430027-0048, 430027-0012)(Oil Cooled)(1100030450, 1300016007) $69.00 NEW IN STOCK |
| Turbine Wheel | 451311-0014 (451311-0003, 451311-0004, 451311-0013)(Ind. 58.9 mm, Exd. 48.69 mm, Trm 10.14, 11 Blades)(1900011104B) $113.60 NEW IN STOCK |
| Comp. Wheel | 409096-0014 (103217-0000, 442198-0001)(Ind. 42.52 mm, Exd. 60.09 mm, Trm 5, 6+6 Blades, Superback) $55.40 NEW IN STOCK |
| Back plate | 409629-0003 (409629-0001, 409629-0006, 409629-0007, 409629-0010, 409629-0016)(1100030300) $22.40 NEW IN STOCK |
| Heat shield Number | 409639-0000 (409627-0000, 4062301)(103121-0000) $14.80 NEW IN STOCK |
| Repair Kit | 707897-0001 (200115-0000, 3545830)(1100030750, 5000010031)(Dynamic) $69.50 NEW IN STOCK |
| Turbine Housing | 430394-0012 (430026-0012)(2035772)(1100030820) $232.22 NEW IN STOCK |
| Compressor Cover | 409589-0100 |
| Turbine Housing AR | 0.48 |
| Gasket (turbine inlet) | 409039-0001 (210190, 210190-0000, 312617, 132044)(Stainless Steel, Single Port) $13.20 |
| Gasket (turbine outlet) | 210275 (Stainless Steel) |
| Gasket oil inlet | 210023 (210023-0000, 147837, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037)(Paper) $4.48 |
| Gasket (oil outlet) | 210021 (210021-0000, 409037-0000, 413671-0000, 3519807, 311496) (1900000027) (Paper) $4.48 |
| Manufacturer | Honeywell-Garrett |
1986-91 Fiat Croma IE with M.601.HT.20.0 Engine
