| Part Number | 705306-5007S |
| Previous Version | 705306-0007, 705306-7 |
| OE Number | 144114U100, 14411-4U100, 14411-4U110, 144114U110 |
| Year | 2000-2003 |
| Description | Almera Tino Di |
| CHRA | 702246-0005 |
| Engine | YD22DDT, YD1 (HS) TD1 |
| Displacement | 2.2L, 2200 ccm, 4 Cylinders |
| KW | 84/114 HP |
| RPM Max | 4000 |
| Fuel | Diesel |
| Angle α (compressor housing) | 240� |
| Angle β (turbine housing) | 137� |
| Bearing Housing | 713632-0001 |
| Turbine Wheel | 434713-0005 (433298-0030) |
| Comp. Wheel | 436132-0003 (replaces 436132-3/703925-3) |
| Back plate | 700593-0004 |
| Heat shield Number | 480277-0002 |
| Repair Kit | 732252-0001 $97.60 |
| Turbine Housing | 430609-0376 |
| Compressor Cover | 714089-0001 |
| Turbine Housing AR | 0.35 |
| Actuator | 433489-0035 |
| Settings Waste gate (pressure) | 1.15-1.21/1.41-1.50 bar |
| Settings Waste gate (lift shaft) | 0.38/4.00 mm |
| Gasket (turbine inlet) | 210549 |
| Gasket (turbine outlet) | 210550 |
| Gasket oil inlet | 210351 |
| Gasket (oil outlet) | 210829 |
| Gasket (turbine inlet)(compressor housing) | 210855 |
| Gasket (turbine outlet)(compressor housing) | 210383 |
| Manufacturer | Honeywell-Garrett |
2000-2003 Nissan Almera Tino with YD22DDTI Engine
