Part Number | 53039880003 |
Previous Version | 5303-988-0003, 5303 988 0003 |
OE number | 028145701R |
Year | 1993-09 |
Description | Commercial Golf III, Vento TD, Passat III TD, Ibiza, Cordoba TD, Toledo TD, Audi A4, 80 TD |
Manufacturer Part Number | 53039700003 |
CHRA | 433289-0050 (433289-5050SS, 433289-0127, 433289-0074, 433289-0077, 433289-0014)(1102015908, 1000010009) $250.00 NEW IN STOCK, MADE IN USA |
Turbo Model | K03-1870EAA3.81KCAAD |
Engine | AAZ, 1.9L 'Umwelt-Diesel' |
Displacement | 1.9L, 1896 ccm, 4 Cylinders |
KW | 55/75 HP |
RPM Max | 4400 |
Fuel | Diesel |
Angle α (compressor housing) | 337.5� |
Angle β (turbine housing) | 45� |
Bearing Housing | 433275-0002 (713782-0002, 433275-0005, 435793-0002, 713782-0010)(Oil Cooling)(1102015450, 1900011012) $67.00 NEW IN STOCK |
Turbine Wheel | 433290-0042 (433158-0001, 433158-0005, 433290-0004, 434712-0020)(Ind. 42.29 mm, Exd. 32.2 mm, 10 Blades)(1102015437, 1100011008) $95.00 NEW IN STOCK |
Comp. Wheel | 433287-0004 (Ind. 33.02 mm, Exd. 43.99 mm, 6+6 Blades, Superback)(1102015413, 1200011003) $48.40 NEW IN STOCK |
Back plate | 703682-0006 (433254-0001)(OD 95 mm/10 mm P/Ring)(1102015308, 1300011023) $20.80 NEW IN STOCK |
Heat shield | 434302-0001 (434685-0001)(1102015343, 2030016026) $14.82 NEW IN STOCK |
Repair Kit | 732252-0001 (1102015756, 5000010067) $66.80 NEW IN STOCK |
Turbine Housing | 53031009004 |
Compressor Cover | 53031015009 |
Turbine Housing AR | 3 |
Actuator | 58201104500 |
Settings waste gate (pressure) | 1.000 bar |
Settings Waste gate (lift shaft) | 3.70 mm |
Gasket (turbine inlet) | 210292 |
Gasket (turbine outlet) | 210296 |
Gasket (turbine inlet) | 210317 |
Manufacturer | Borg Warner - 3K - Schwitzer |
1995-98 Volkswagen Commercial Vento with AAZ Engine
1993-09 Volkswagen Golf III, Passat III TD, Vento TD with AAZ Engine
1994-03 Audi 80 TD with AAZ Engine
1996-03 Audi A4 with AAZ Engine
1993-09 Seat Cordoba TD, Ibiza, Toledo TD with AAZ Engine
