Part Number | 454083-5002S |
Previous Version | 454083-0001, 454083-0002, 454083-2 |
OE number | 95VW6K682AA, 1002829, 028145701Q |
Year | 1995-99 |
Description | Volkswagen Golf, Passat Seat Toledo |
CHRA | 433289-0050 (433289-5050SS, 433289-0127, 433289-0074, 433289-0077, 433289-0014)(1102015908, 1000010009) $250.00 NEW IN STOCK, MADE IN USA |
Turbo Model | GT1544S |
Engine | TDI 90 |
Engine Manufacturer | VW |
Displacement | 1.9L, 1896 ccm, 4 Cylinders |
KW | 90/110 |
RPM Max | 4000/4400 |
Fuel | Diesel |
Angle α (compressor housing) | 273� |
Angle β (turbine housing) | 190� |
Bearing Housing | 433275-0002 (713782-0002, 433275-0005, 435793-0002, 713782-0010)(Oil Cooling)(1102015450, 1900011012) $67.00 NEW IN STOCK |
Turbine Wheel | 433290-0042 (433158-0001, 433158-0005, 433290-0004, 434712-0020)(Ind. 42.29 mm, Exd. 32.2 mm, 10 Blades)(1102015437, 1100011008) $95.00 NEW IN STOCK |
Comp. Wheel | 433287-0004 (Ind. 33.02 mm, Exd. 43.99 mm, 6+6 Blades, Superback)(1102015413, 1200011003) $48.40 NEW IN STOCK |
Back plate | 703682-0006 (433254-0001)(OD 95 mm/10 mm P/Ring)(1102015308, 1300011023) $20.80 NEW IN STOCK |
Heat shield | 434302-0001 (434685-0001)(1102015343, 2030016026) $14.82 NEW IN STOCK |
Repair Kit | 732252-0001 (1102015756, 5000010067) $66.80 NEW IN STOCK |
Turbine Housing | 435788-0016 |
Compressor Cover | 435791-0056 |
Turbine Housing AR | 0.35 |
Actuator | 435176-0020 |
Settings Waste gate (pressure) | 0.770-0.830 bar |
Settings Waste gate (lift shaft) | 1.00 mm |
Gasket (turbine inlet) | 210505 (Steel) $11.50 |
Gasket (turbine outlet) | 210534 (Steel) |
Gasket (oil outlet) | 210243 (Paper) $4.00 |
Manufacturer | Honeywell-Garrett |
Condition | Rebuilt |
Interchangeable with 53039880006
1995- Ford Galaxy with TDI 90 Engine
1995-97 Seat Toledo TDI with TDI 90 Engine
1997- Seat Alhambra TDI with TDI 90 Engine
1997-99 Seat Cordoba TDI with TDI 90 Engine
1997- Seat Ibiza TDI with TDI 90 Engine
1995-97 Volkswagen Passat TDI with TDI 90 Engine
1995- Volkswagen Sharan TDI / Vento TDI with TDI 90 Engine
1995-97 Volkswagen Golf TDI with TDI 90 Engine
