Part Number | 466794-0001 |
Previous Version | 466794-0001, 466794-0002 |
OE Number | 1328579, 5003566, 1328579, 072145703, 72145703, 072 145 703 (072145703) |
Description | Volvo 400, 700, 900 |
CHRA | 409853-0018 (409853-5018S, 409853-0048, 409853-0004, 409853-0044, 409853-0018, 409172-0069, 409853-0061)(1100030900, 300020003, 576026C91) $295.00 NEW IN STOCK, MADE IN USA |
Turbo Model | TB0349 |
Engine | D24TIC, B240 |
Engine Manufacturer | Volvo |
Displacement | 2.5L, 2383 ccm, 6-Cyl. i/c, Diesel |
KW | 85/90 |
RPM Max | 4000 |
Fuel | Diesel |
Angle α (compressor housing) | 85� |
Angle β (turbine housing) | 158� |
Bearing Housing | 430027-0025 (312379, 407285-0027, 407285-0038, 430027-0022, 430027-0048)(Oil Cooled) $69.00 NEW IN STOCK |
Turbine Wheel | 451310-0003 (451310-0006)(Ind. 65. mm, Exd. 49.06 mm, 11 Blades)(1100030436, 1100030438) $97.20 NEW IN STOCK |
Comp. Wheel | 409096-0014 (103217-0000, 409096-0005, 442198-0001)(Ind. 42.52 mm, Exd. 60.09 mm, 6+6 Blades, Superback)(1100030402) $54.32 NEW IN STOCK |
Back plate | 409629-0003 (409629-0001, 409629-0006, 409629-0007, 409629-0010, 409629-0016)(1100030300) $30.00 NEW IN STOCK |
Heat shield Number | 409627-0000 (103121-0000)(1100030340) $14.80 NEW IN STOCK |
Repair Kit | 707897-0001 (200115-0000, 3545830)(dynamic seal)(1100030750) $71.00 NEW IN STOCK |
Turbine Housing | 431398-0011 |
Compressor Cover | 409589-0094 (432022-0001) |
Turbine Housing AR | 0.36 |
Actuator | 443700-0008 |
Settings Waste gate (pressure) | 0.87-0.93 bar |
Settings Waste gate (lift shaft | 0.38 mm |
Gasket (turbine inlet) | 409039-0001 (409039-0000, 210019, 2405022) $13.52 |
Gasket (turbine outlet) | 210225 (Stainless Steel) $24.90 |
Gasket oil inlet | 210023 (409026-0001, 409036-0000, 147837, 215234, 52231586500)(1900000037) $4.48 |
Gasket (oil outlet) | 210021 (409037-0000, 413671-0000, 409266-0001, 147837, 3755739, 3709737, 3500681, 55739, 3519762)(1900000027) $3.32 |
Manufacturer | Honeywell-Garrett |
1987-92 Volvo 760 TD Engine D24TIC
1987-92 Volvo 765 TD Engine D24TIC
1991- Volvo 940 TD Engine D24TIC
1991- Volvo 960 TD Engine D24TIC
