| Part Number | 316153 |
| Previous Version | 312195, 312195K, 313815 |
| OE number | 35242030G, 312195K |
| Year | 1997-02 |
| Description | Industrial |
| Manufacturer Part Number | 312195K, 312195 |
| CHRA | 316152 $695.23 NEW IN STOCK |
| Turbo Model | S1BG |
| Engine | HR394HPT |
| Displacement | 2.08L, 2080 ccm |
| KW | 55/74 |
| RPM Max | 4200 |
| Fuel | Diesel |
| Angle α (compressor housing) | 273� |
| Angle β (turbine housing) | 180� |
| Bearing Housing | 316147 (Oil Cooled)(1900011213C) $154.80 NEW IN STOCK |
| Turbine Wheel | 312880 (Ind. 47. mm, Exd. 40. mm, Trm 6.07, 12 Blades)(1252201435, 1100016215) $167.20 NEW IN STOCK |
| Comp. Wheel | 314399 (Ind. 41.3 mm, Exd. 58. mm, 6+6 Blades, Superback)(1200020272) $151.06 NEW IN STOCK |
| Back plate | 196872 (315910)(1252201300, 1800016064) $26.47 NEW IN STOCK |
| Heat shield Number | 311863 (1252201340, 2030016099) $12.57 NEW IN STOCK |
| Repair Kit | 318374 (312943, 315360, 313809)(1252201750, 5000030016) $95.00 NEW IN STOCK |
| Turbine Housing | 312381 |
| Compressor Cover | 312386 |
| Actuator and hose assembly | 312569 $155.42 |
| Settings Waste gate (pressure) | 0.965-1.006 bar |
| Settings Waste gate (lift rod) | 0.38 mm |
| Gasket (turbine inlet) | 311698 (Inox Steel) $16.36 |
| Gasket Kit | 318421 (1900100166) $15.70 |
| Turbine outlet adapter | 312101 $16.65 |
| Manufacturer | Borg Warner - 3K - Schwitzer |
Note: Replacement for OE S1A 312195 and Aftermarket 313815
1997-02 VM Motori Industrial Engine with HR394HPT Engine
