Part Number | 465472-5007S |
Previous Part Number | 465472-0007, 465472-0003, 465472-7 |
OE number | 124613-18030, 12461318030 |
Description | Marine, Gen Set |
Manufacturer Part Number | Yanmar |
CHRA | 408105-0200 (408105-0374, 408105-0143, 408105-0051, 408105-0260) $300.00 NEW IN STOCK, MADE IN USA |
Turbo Model | T04B82 |
Engine | 6PH-T, 6PH-HT |
Displacement | 6 Cylinders |
Engine Manufacturer | Yanmar |
Fuel | Diesel |
Angle a (compressor housing) | 220º |
Angle ß (turbine housing) | 200º |
Bearing Housing | 430027-0022 (312379, 407285-0027, 407285-0038, 430027-0025, 430027-0048)(Oil Cooled) $69.00 NEW IN STOCK |
Turbine Wheel | 446905-0007 (155-5236)(410188-0003, 446905-0005, 446905-0002, 446905-0010, 451309-0003, 407276-0006, 407276-0019, 410188-0006, 410188-0037, 451309-0004)(Ind. 64. mm, Exd. 73. mm, Trm 77, 11 Blades)(1100016090) $144.50 NEW IN STOCK |
Comp. Wheel | 409179-0024 (31534, 79031534, 684364C1)(Ind. 44.15 mm, Exd. 70. mm, 8+8 Blades, Superback/Stepped)(1200016008) $39.00 NEW IN STOCK |
Back plate | 408045-0034 (AR101787, 310010, 4062086, 74062086, 630614C91, 303227367, 311708, 4N6863, 331640804534, 104244-0000)(408206-0002, 408045-0006, 408206-0002, 408045-0040, 408045-0051)(1100040360, 1300016009) $22.40 NEW IN STOCK |
Heat shield Number | 409299-0001 (409299-0000) $15.70 NEW IN STOCK |
Repair Kit | 468100-0000 (3524796, 168984, 2W0716, 6N7236, 310063, 188401-0000, 188006-0000)(1100040750, 5000010041) $69.00 NEW IN STOCK |
Turbine Housing | 409099-0032 |
Compressor Cover | 408274-0024 $90.65 |
Turbine Housing AR | 0.84 |
Gasket (turbine inlet) | 407294-0001 (310694) $13.84 |
Gasket oil inlet | 210023 (210023-0000, 147837, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037)(Paper) $4.48 |
Gasket (oil outlet) | 210021 (409037-0000, 413671-0000, 210021-0000, 311496, 413671-0000, 3519807)(1900000027) $3.32 |
Replaced by | 465472-0003 |
Manufacturer | Honeywell-Garrett |
Yanmar Marine with 6PH-T,6PH-HT Engine
