Part Number | 465114-5005S |
Previous Version | 465114-0005, 465114-0003, 465114-5 |
OE number | 4845243, 4029207, 4036513, 4062751 |
Description | Ford Tractor 8630, Tractor, Fiat-Allis F28 Agricultural Tractor Earth Moving |
CHRA | 408105-0374 (408105-0260, 408105-0143, 408105-0051, 408105-0200)) |
Turbo Model | T04B66 |
Engine | CNH, 8365.25.512, 8365.25.513, 8365.25.514, 8365.25.515 Iveco |
Engine Manufacturer | FIAT, Iveco |
Displacement | 8.1L, 8100 ccm |
KW | 160/180 |
RPM Max | 2200 |
Fuel | Diesel |
Angle α (compressor housing) | 0° |
Angle β (turbine housing) | 0º |
Bearing Housing | 430027-0022 (312379, 407285-0027, 407285-0038, 430027-0025, 430027-0048)(Oil Cooled) $69.00 NEW IN STOCK |
Turbine Wheel | 446905-0007 (155-5236)(410188-0003, 446905-0005, 446905-0002, 446905-0010, 451309-0003, 407276-0006, 407276-0019, 410188-0006, 410188-0037, 451309-0004)(Ind. 64. mm, Exd. 73. mm, Trm 77, 11 Blades) $144.50 NEW IN STOCK |
Comp. Wheel | 09179-0024 (31534, 79031534, 684364C1)(Ind. 44.15 mm, Exd. 70. mm, 8+8 Blades, Superback/Stepped) $39.00 NEW IN STOCK |
Back plate | 408045-0051 (AR101787, 310010, 74062086, 630614C91, 303227367, 311708, 408206-0002, 408045-0006, 408206-0002, 408045-0034, 4N6863, 331640804534, 104244-0000)(1100040360) $22.40 NEW IN STOCK |
Heat shield Number | 409299-0001 (409299-0000) $15.70 NEW IN STOCK |
Repair Kit | 468100-0000 (3524796, 168984, 2W0716, 6N7236, 310063, 188401-0000, 188006-0000)(1100040750) $69.00 NEW IN STOCK |
Turbine Housing | 408565-0015 |
Compressor Cover | 408173-0064 |
Turbine Housing AR | 1.15 |
Gasket (turbine inlet) | 409039-0000 (409039-0001, 210019, 312617, 2405022, 7C7431)(1900000006)(Inox Steel) $13.52 |
Gasket (turbine outlet) | 210226 (2405066) (Stainless Steel) $29.00 |
Gasket oil inlet | 210023 (210023-0000, 147837, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037)(Paper) $4.48 |
Gasket (oil outlet) | 210021 (409037-0000, 413671-0000, 210021-0000, 311496, 413671-0000, 3519807)(1900000027) $3.32 |
Replaces | 352540 |
Manufacturer | Honeywell-Garrett |
Ford Tractor 8630, Tractor 8830 Excavator with CNH Engine
Fiat-Allis F28 Agricultural Tractor Excavator with 8365.25.512, 8365.25.513, 8365.25.514, 8365.25.515 Iveco Engine
