| Part Number | 171963 |
| Previous Version | 171964 |
| OE number | 1956029, 195-6029, 195-6031, 1956031 |
| Application | 938G, 950G, 962G Wheel Loaders |
| Description | Earth Moving |
| CHRA | 171965 (1987374) $752.69 |
| Turbo Model | S200G, S200G052 |
| Engine Model | 3126 |
| Displacement | 7.0L, 7000 ccm |
| KW/RPM | 116/2200 |
| Machine Engine | 3126 |
| Integrated Tool Carrier | IT38G, IT62G |
| Wheel-Type Skidder | 525B, 535B |
| Wheel-Type Loader | 938G, 950G, 962G |
| S/N | 55K7976-UP, 6JK8177-8177, 6JK8180-8180, 6JK8182-8182, 6JK8193-UP, 55K7975-UP |
| Fuel | Diesel |
| Angle α (compressor housing) | 95° |
| Angle β (turbine housing) | 356° |
| Bearing Housing | 171966 |
| Turbine Wheel | 167729 $594.49 |
| Comp. Wheel | 171967 |
| Back plate | 167744 $83.38 |
| Heat shield Number | 167745 $17.79 |
| Repair Kit | 318382 $97.60 |
| Turbine Housing | 171162 |
| Compressor Cover | 169749 |
| Actuator | 171160 |
| settings Waste gate (pressure) | 1,558-1,627 bar |
| settings Waste gate (lift shaft) | 0.38 mm |
| Gasket (turbine inlet) | 409039-0000 |
| Gasket (turbine outlet) | 210245 |
| Gasket (oil outlet) | 210021 |
| NOTE | Re-circulation groove in compressor housing |
| Replaced by | 178478 |
| Manufacturer | Borg Warner - 3K - Schwitzer |
2000- Caterpillar 938G, 950G, 962G Wheel Loaders With 3126 Engine
