Part Number | 403680-5001S |
Previous versions | 403680-0001, 403680-9001, 403680-0012. ,403680-0023, 403680-1 |
OE number | 2M5488, 3S8271 |
Description | Earth Moving 583H-Pipe layer, D8/D8H-Tractor |
CHRA | 406614-0002 (406614-9006, 2M7888, 406614-5006, 0R5880, 3S7804) $2,818.50 NEW IN STOCK (Listed $4759.27) |
Turbo Model | T1404 |
Track-Type Tractor | D8H |
Model | 583H |
Engine | D342 |
Fuel | Diesel |
Displacement | 6L Cylinders |
Engine | D8H, 583H |
Pipe layer | 583H |
Track-Type Tractor | D8H |
S/N | 36A1 to 36A883 inclusive, 36A884 to 36A2250 inclusive, 36A2251 to 36A3052, 36A3055 to 36A3062 inclusive, 36A3053, 36A3054 and 36A3063-Up, 38A1 to 38A53 inclusive, 38A54 to 38A76 inclusive, 38A77, 46A1 to 46A228 inclusive, 46A229 to 46A2218 inclusive, 46A2219, 36A00001-03859, 38A00001-00078, 46A00001-03043, 46A03044-10724, 36A03860-04468 |
Bearing Housing | 403394-0000 (8M0004, 490200) $924.95 |
Turbine Wheel | 407245-0000 (7S8444) $1575.44 |
Comp. Wheel | 406597-0002 (3S7805) $632.36 |
Back plate | 405777-0001 |
Heat shield Number | 403499-0000 (114020) |
Repair Kit | 468115-0000 NEW IN STOCK |
Diaphragm Assem | 403499-0000 (2M2560) $70.78 |
Plate Diffuser | 406615-0002 (2S6912) $161.84 |
Shim 0.040 (Heat shield) | 402175-0000 (2M8049) $168.95 |
Shim 0.010 (Heat shield) | 402175-0000 (2M2558) $16.26 |
Plate Lock | 2M8050 |
Shim | 401718-0002 (2M8051) (.020 & quot, thick) $10.04 |
Shim | 401718-0001 (2M2556) (.005 & quot, thick) $10.04 |
Nozzle Ring | 402083-0023 |
Turbine Housing | 402172-0000 (5M3688) $1692.57 |
Compressor Cover | 402174-0044 (4M4411) $1493.22 |
Turbine Housing AR | 2.30 |
Gasket oil inlet | 210019 $8.40 |
Gasket (oil outlet) | 210018 (129120) $8.22 |
Gasket (Heat shield) | 404569-0000 |
Nozzle Gasket | 400866-0000 (5H8641) $16.98 |
Gasket | 8H1858 (Metal) $8.14 |
Replaced By | 403680-0023, 403680-0012 |
Manufacturer | Honeywell-Garrett |
Caterpillar Earth Moving D8H, 583H with D342 Engine
