Part Number | 196549 |
Previous versions | 178105, 178105R, 178781R, 194598, 194598R, 194781, 194781R, 196549, 196549R, 312006 |
OE number | 0R5728, 412006, 478105, 494598, 494781, 496549, 7C0453, 7C0489, 7C6712, 7C7687 |
Description | Truck Earth Moving |
CHRA | 169415 (199115, 0R7195, 0R6172, 1412023, 178171, 478171, 469415, 4P2525) $425.00 NEW IN STOCK, MADE IN USA |
Turbo Model | S4AS-010 |
Prefix | 3ZJ, 4MG, 5KJ, 7FB, 7XC, 8TC |
Engine | 3406B, 3406 |
Use on | 3406C 3ZJ, 3406C 5KJ, 3406B 4MG, 3406B 5KJ, 3406B 7FB, 3406B 8TC |
Fuel | Diesel |
Truck Engine | 3406B, 3406C |
S/N | 7FB86073-UP & 4MG1-3599, 8TC988-UP, 8TC1413-14475, 3ZJ61789-61796, 3ZJ61798-61799; 3ZJ61807-61807, 3ZJ61815-61831 |
Bearing Housing | 199143 (199144, 4P3627)(Oil Cooled) $112.90 NEW IN STOCK |
Turbine Wheel | 189553 (7W3842)(6115014684685)(Ind. 84.9 mm, Exd. 96.4 mm, 12 Blades) $174.00 NEW IN STOCK |
Comp. Wheel | 169413 (4P3624, 1412010)(Ind. 75.15 mm, Exd. 98.99 mm, Trm 10.34, 6+6 Blades) $189.66 NEW IN STOCK |
Back plate | 197651 (51135, 5S4556, 142066, 49162-22500, 52321523000, 52321523001, 143044-0000)(1250403300) $19.50 NEW IN STOCK |
Heat shield Number | 187517 (4W7355) $19.50 NEW IN STOCK |
Repair Kit | 318406 (318408)(311144)(1252419755) $123.00 NEW IN STOCK |
Turbine Housing | 194599 (7C0454) $634.08 |
Compressor Cover | 194007 (7W8425) $504.39 |
Turbine Housing AR | 6.15/1.58 |
Gasket (turbine inlet) | 409038-0000 (1S4295, 132040, 52231083002, 210835-0000, 9749, 7M7273, 7H1558, 8N2835) $13.20 |
Gasket oil inlet | 210019 (409266-0004, 210019-0000, 201049, 129119, 409266-0003)(Paper) $3.22 |
Gasket (oil outlet) | 210018 (3519763, 129120, 210018-0000, 201048, 157602, 3037537)(Paper) $3.22 |
Gasket Kit | 318417 $17.44 |
NOTE | Use 194781, replaced by 199086 in '91, Requires spacers or oil line change for S3B |
NOTE | Requires spacers or oil line change for S3B |
Replaced by | 312006 |
Manufacturer | Borg Warner - 3K - Schwitzer |
1987-01 Caterpillar Truck, Earth Moving With 3406B Engine
