Product Description

Part Number	407640-5009S
Previous Version	407640-0001, 407640-0002, 407640-0004, 407640-0011,407640-0013, 407640-1, 407640-2, 407640-4, 407640-11,407640-13
OE number	0R5378, 8S6832, 8S8039, 8S-8039
Description	Earth Moving Engine And Power Units, Caterpillar 627B-2-Wheel Tractor , 627-Scraper, 627B-Scraper, Marine
CHRA	407505-0015 (407505-9015, 407505-5015S, 7N7248, 8S6832, 8S6833, 8S8041, 0R5912)(1100120701) $854.39
Turbo Model	T1224
Displacement	10500 ccm, 6 Cylinders
Engine	3306 PCT 101, D333C, 3306, 3306T
Equipment Model	627, 627B, 637
KW	172/230/304
Fuel	Diesel
Earth Moving Compactor	816, 815
Generator	SR4
Industrial Engine	SR4, 3306, D333C
Marine Engine	3306, D333C
Excavator	235
Machine Engine	3306
Motor Grader	120, 12F, 12G, 140, 140G, 14E, 14G
Pipe layer	561C, 571F, 571G, 572F, 572G
Truck Engine	1673C, 3306
Track-Type Loader	997K
Track-Type Tractor	D5, D6C, D7F, D7G
Wheel-Type Skiddeer	528
Wheel-Type Loader	966C, 980B
Wheel Tractor-Scraper	627, 627B, 637, 637B, 627, 627B
Wheel Dozer	814
Engine Serial No	3N49744 to 3N86459 inclusive
S/N	66D49919-UP, 69D454-Up, 67D517
Angle α (compressor housing)	208°
Angle β (turbine housing)	0°
Bearing Housing	406866-0004 (7N7252, 3S4480, 4S9702, 112023-0000) (1100120450) $386.26 NEW IN STOCK
Turbine Wheel	406845-0005 (8S5167, OR5396, 112011-0000) (Ind. 88.4 mm, Exd. 77.7 mm, 11 Blades) (1100120436) $412.36 NEW IN STOCK
Comp. Wheel	408126-0006 (8S5168, 112016-0000) (Ind. 58.46 mm, Exd. 84.12 mm, 6+6 Blades) (1100120401) $204.54 NEW IN STOCK
Back plate	406834-0002 (406308-0000, 3S4486, 4S6479, 8S5169) (1100120300) $179.99 NEW IN STOCK
Heat shield Number	409368-0000 (3S4490, 9S9327, 7N3760, 407574-0002, 407778-0001, 112121-0000) (1100120340) $62.52 NEW IN STOCK
Repair Kit	468109-0000 (3545839, 2W0719, 6N7239, 468177-0000, 468108-0000, 409282-0000, 112098-0000, 188402-0000, 188411-0000) (1100120753) $94.00 NEW IN STOCK
Turbine Housing	406482-0023 (8S5165) $619.43
Compressor Cover	407009-0073 (8S5166) $854.39
Turbine Housing AR	1.34
Gasket (turbine inlet)	409038-0000 (9749, 1S4295, 202873, 205396, 3500683, 132040, 210017-0000)(1900000003) $13.20
Gasket oil inlet	129119 (201049, 9737, 1S6595, 210019-0000, 409266-0003, 3819900)(1900000035) $4.38
Gasket (oil outlet)	210018 (129120, 210018-0000, 409267-0002, 3709738, 3500682, 201048, 1S4810, 9988, 9738, 3519763) (1900000025) $4.38
Replaced By	465984-0003
Manufacturer	Garrett
