Product Description

Part Number	409410-5002S
Previous Version	409410-0002, 409410-0001, 409410-0003, 409410-0009
OE number	4N6859, 0R5799, 1P9136, 4N-6859, 0R-5799, 1P-9136
Description	Caterpillar 120, 120G, 130G, 225, 518, 950, 950-Wheel Loader, 518-Skidder 3304-Engine, Industrial, Excavator (3304) Earth Moving
CHRA	408077-0102 (408077-5102S, 4N6860, 4N4780, 0R5888) $313.04 NEW IN STOCK, MADE IN USA
Turbo Model	T0491
Prefix	2CB, 76W, 77W, 7PB, 04B, 05B, 4PC, 6YB, 20S, 50S,55U, 49U, 81J, 11W, 87V, 09Y, 12W, 74V, 85J
Engine	3304-Engine/Industrial, 3304T PCT GS DIT
Fuel	Diesel
Displacement	7000 ccm, 4 Cylinders
Machine Engine	3304
Generator Set Engine	3304
Generator	SR4
Industrial Engine	SR4, 3304, D330C
Excavator	225
Motor Grader	120G, 130G
Track-type Loader	941, 941B, 951B, 951C, 955K, 955L
Track-type Tractor	D4D, D4E
Wheel-type Skidder	518
Wheel-Type Loader	920, 930, 950
S/N	04B26769-UP, 48V9698-Up, 43V10541-UP, 43V1033, 43V1047, 43V118, 43V1302~43V1772, 43V1778~43V10540, 78P1 to 78P8259 inclusive, 81J3781-Up and 31K968-Up, 43J2874 to 43J3129, 43J3131, 43J3132, 43J3135, 43J3138, 43J3145, 43J3149, 43J3192 to 43J3194 and 43J3196-Up, 48V1 to 48V9697 inclusive, 43V1~43V1032, 43V1034~43V1046, 43V1048~43V1117, 43V1119~43V1301, 43V1773~43V177, 4PC00001-UP, 6YB00001-UP, 2CB00001-UP, 7PB00001-UP, 71H00260-UP, 73J07258-UP, 73J03957-07257, 07R00508-00758, 04B07794-14448, 31K01201-01485, 04B26769-UP, 04B14449-26768, 50S01289-03229, 31K01486-UP, 43J06268-UP
Angle α (compressor housing)	168º
Angle β (turbine housing)	15º
Bearing Housing	430027-0051 (430027-0035, 430027-0031)(2P9635) $49.20 NEW IN STOCK
Turbine Wheel	451309-0003 (1P1116, 1555236)(446905-0007)(Ind. 74.5 mm, Exd. 64.7 mm, 11 blades) (1100040436) $198.82 NEW IN STOCK
Comp. Wheel	409179-0018 (4N6861)(Ind. 48.35 mm, Exd. 70. mm, Trm 50, 8+8 blades, S-Trim, Stepped back)(1100040400) $69.00 NEW IN STOCK
Back plate	408045-0051 (311708C, 4N6863)(408206-0002, 408045-0006, 408045-0034, 310010, 311708, 104244-0000) (Dynamic) (1100040360) $13.22 NEW IN STOCK
Heat shield Number	409299-0001 (7N0012) $29.50 NEW IN STOCK
Repair Kit	468100-0000 (3524796, 310063, 188401-0000) (6N7236, 2W0716) (1100040750) $61.60 NEW IN STOCK
Turbine Housing	408667-0021 (6N0565) $421.67 NEW IN STOCK
Compressor Cover	408173-0008 (4N6862) $240.03
Turbine Housing AR	1.75
Gasket oil inlet	210023 (55739, 147837, 3500681, 3519762, 3709737, 3755739, 409026-0001, 409036-0000, 409266-0001, 210023-0000) (1900000037) $4.48
Gasket (turbine inlet)	407294-0001 (312617) $8.20
Gasket (oil outlet)	210021 (148062, 311496, 3519807, 409037-0000, 413671-0000)(1900000027) $4.48
Replaced By	409410-9002, 310152, 155431, 312749 3LM
Manufacturer	Honeywell-Garrett
