Part Number | 180460 |
OE number | AR80135, AR69049, AR78444, AR734695 |
Description | Tractor 8630, Scraper 762, Crawler 855, Crawler 850, Earth mover 762/762S Scraper 6619T (500 SERIES) |
Manufacturer Part Number | 180460, 465320-0002, 465320-0003 |
CHRA | 181944 |
Interchangeable CHRA | (409043-9001S, AR73128) $853.77 NEW IN STOCK |
Turbo Model | 4LE-302, 4LE302, TV6102 |
Engine | 6619, 6619A |
Displacement | 10.1L, 10144 ccm, 6 Cylinders |
Fuel | Diesel |
Angle α (compressor housing) | 169/238° |
Angle β (turbine housing) | 352/289° |
Bearing Housing | 159505 (408495-0009, AR73129, 4062624)(4N3956, 5S4543, 4N9540, 8S9224, 148043)(Oil Cooled) $181.67 NEW IN STOCK |
Turbine Wheel | 184409 (0R5391, 5S4544, 8S4989)(Ind. 72.1 mm, Exd. 91. mm, Trm 12.28, 12 Blades)(408493-0006) $281.88 NEW IN STOCK |
Comp. Wheel | 180939 (408455-0029) $340.93 NEW IN STOCK |
Back plate | 197651 (51135, 142066, 5S4556, 52321523000, 52321523001, 49162-22500, 1250403300, 143044-0000) $19.50 NEW IN STOCK |
Heat Shield | 188086 (148046, 4N9556, 8S9221)(409368-0000, 407778-0001) $19.50 NEW IN STOCK |
Repair Kit | 318350 (311603, 407778-0001) $119.21 NEW IN STOCK |
Turbine Housing | 180459 $452.47 (408142-0003) |
Compressor Cover | 159959 (408619-0005) |
Turbine Housing AR | 0.87 |
Gasket (turbine inlet) | 132040 (409377-0000, 210087-0000, 202873, 205396, 205396, 3500683, 210017-0000, 409038-0000, 1S4295, 9749)(1900000003) $14.92 |
Gasket oil inlet | 129119 (409266-0004, 210019-0000, 201049, 129119, 409266-0003, 210019) $4.40 |
Gasket (oil outlet) | 129120 (210018-0000, 409267-0002, 3709738, 3500682, 201048, 1S4810, 9988, 9738, 3519763, 201048, 157602, 3037537)(1900000025) $4.38 |
Interchangeable Turbo Part | 465320-0002, 465320-0003 |
NOTE | Complete replacement turbo. Internal parts not interchangeable |
Manufacturer | Honeywell-Garrett |
John Deere Agricultural Tractor 8630 with 6619A Engine
John Deere Truck Scraper 762/Crawler 855, Crawler 850 with 6619A Engine
It might replace and fit John Deere Earth Moving with OE Number AR73469, AR78444
