Part Number | 452281-5016S |
Previous Version | 452281-0004, 452281-0008, 452281-0009, 452281-0010, 452281-0012, 452281-0014, 452281-0016, 452281-5008S, 452281-16 |
OE number | 1453883, 1609988, 1397101, 1601655, 1344152, 1377426 |
Year | 1999-04 |
Description | DAF Truck CF85, XF95, F95, CF85 |
CHRA | 434251-0046 (434251-5046S) $350.00 NEW IN STOCK, MADE IN USA |
Turbo Model | GT4294S |
Engine | XE355CO, XE315CO, XF355M, XE355C1, XE390C, XE315C2, XE390C0 |
Engine Manufacturer | DAF |
Displacement | 12.6L, 12580 ccm |
KW | 315/355/390/530 HP |
RPM Max | 1900/2000 |
Bearing Housing | 452698-0007 (410310-0004)(Oil Cooled) $66.00 NEW IN STOCK |
Turbine Wheel | 434281-0018 (434281-0021)(Ind. 75.15 mm, Exd. 82. mm, Trm 15.72, 10 Blades) $142.00 NEW IN STOCK |
Comp. Wheel | 434335-0048 (Ind. 67.79 mm, Exd. 94. mm, Trm 16.27, 6+6 Blades) $125.00 NEW IN STOCK |
Back plate | 448890-0007 (448890-0008)(3964367) $34.00 NEW IN STOCK |
Heat shield Number | 410366-0007 (410366-0003, 410366-0004) $16.42 NEW IN STOCK |
Repair Kit | 709153-0005 (709153-0001, 709153-0002)(1102042750) $90.80 NEW IN STOCK |
Turbine Housing | 436737-0004 (436737-0001) |
Compressor Cover | 707709-0094 (707709-0030, 707709-0076, 707709-0082) |
Actuator | 434133-0094 (434133-0052) |
Gasket (turbine inlet) | 132040 (9749, 1S4295, 202873, 205396, 3500683, 210017-0000, 409038-0000)(1900000003)(417382 Replaced by 470939, 20784537) $13.20 |
Gasket (turbine outlet) | 210239 (Stainless Steel) $22.00 |
Gasket oil inlet | 129119 (210019, 201049, 9737, 1S6595, 210019-0000, 409266-0003, 3819900, 129120)(417378 Replaced by 420641)(1900000035) $4.38 |
Gasket (oil outlet) | 210060 (409267-0003, 409267-0002, 210060-0000, 210018-0000, 51914, 148062, 129120, 311585, 201048, 1S4810, 9988, 9738, 3709738, 3500682, 3519763)(Paper)(1900000025) $4.48 |
Replaced By | 451281-0018, 53319887145 |
Manufacturer | Honeywell-Garrett |
1999-04 DAF Truck CF85, XF95, F95, CF85 with XE355CO, XE315CO, XF355M, XE3 Engine
2000- DAF 95XF .530 with XE355C Engine
2000- DAF 95XF .530 with XE390C0 Engine
