Part Number | 465640-5022S |
Previous Version | 465640-0013, 465640-0022, 465640-0003, 465640-0002, 465640-0026, 465640-0006, 465640-5015S, 465640-0015 |
OE Number | 4762527, 79076287, 4812547, 4718129, 4810230 |
Description | Iveco Tractor, Truck, Fiat-Allis Military, Ford Tractor 8830/8640/8430 |
CHRA | 408105-0281 (408105-0083, 408105-5281S) $300.00 NEW IN STOCK, MADE IN USA |
Turbo Model | T04B49 |
Engine | 8062.25.670, 8065.24.300 |
Engine Manufacturer | Iveco |
Displacement | 5.5L, 5861 ccm, 6 Cylinders |
KW | 144/170/172 |
RPM Max | 2400/3000 |
Fuel | Diesel |
Angle α (compressor housing) | 0° |
Angle β (turbine housing) | 0° |
Bearing Housing | 430027-0025 (186879, 186881)(1100030450) $86.96 NEW IN STOCK |
Turbine Wheel | 446905-0001 (451309-0002)(AR57715, 310094A, 317640, 407276-0005, 410188-0014, 410188-0005, 314655)(Ind. 58.35 mm, Exd. 74.2 mm, Trm 46, 11 Blades)(1100040435) $149.00 NEW IN STOCK |
Comp. Wheel | 409179-0028 (Dia. 70.00 mm, Ind. 43.70 m, Exd. 5.10 mm, Trm 39, 8 Blades) $81.42 NEW IN STOCK |
Back plate | 408045-0034 (408206-0002, 408045-0051, 408045-0006, 4N6863, 104244-0000, 310010, 311708, 197340, AR101787)(1100040360) $38.66 NEW IN STOCK |
Heat Shield | 409299-0000 (409299-0001)(311943, 7N0012, 3524773B) $29.50 NEW IN STOCK |
Repair Kit | 468100-0000 (188401-0000, 310063, 3524796, 2W0716, 6N7236)(1100040750) $69.60 NEW IN STOCK |
Turbine Housing | 432752-0052 |
Compressor Cover | 408173-0518 |
Turbine Housing AR | 1.00 |
Gasket (turbine inlet) | 409039-0000 (Inox Steel)(409039-0001, 210019, 2405022)(1900000006) $13.52 |
Gasket (turbine outlet) | 210315 (Stainless Steel) |
Gasket (oil outlet) | 311496 (210021, 3519807, 413671-0000, 409037-0000)(1900000027) $4.48 |
Gasket (oil inlet) | 147837 (210023, 55739, 3755739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 210023-0000)(1900000037) $4.48 |
Manufacturer | Honeywell-Garrett |
Ford Tractor 8830/8640/8430 with CNH Engine
1983- Fiat-Allis Agricultural Tractor with 8065.24.301 Engine
Iveco Tractor 80.17 4WD with 8062.25.670 Engine
Fiat-Allis Military with 8060.25.680 Engine
