| Part Number | 466074-5011S |
| Previous Version | 466074-0011, 466074-0001, 3526963, 312389 |
| OE number | 468996, 470387, 863501, 5002778 |
| Description | Truck F12, N12/NL12 |
| CHRA | 441398-0026 (441398-5026S) $295.00 NEW IN STOCK, MADE IN USA |
| Turbo Model | TA5101 |
| Engine | TD120G/GA/121G, TD120G, TD121G, TD120GA |
| Displacement | 11.98L, 11950 ccm, 6 Cylinders |
| KW | 298/400 |
| Angle α (compressor housing) | 180° |
| Angle β (turbine housing) | 360° |
| Bearing housing | 410310-0001 (311548)(432351-0021, 479802-0002) $66.00 NEW IN STOCK |
| Turbine Wheel | 441194-0001 (314407)(431126-0001, 431126-0002, 432620-0002, 435257-0001, 435257-0002, 435737-0005, 435922-0001)(Ind. 88.9 mm, Exd. 77.7 mm, Trm 76, 11 Blades) $101.80 NEW IN STOCK |
| Comp. Wheel | 441792-0007 (312595)(431350-0001, 431350-0007, 431350-0015)(Ind. 64.25 mm, Exd. 91.00 mm, Trm 50, 6+6 Blades, Superback) $58.40 NEW IN STOCK |
| Back plate | 442752-0002 (430612-0003, 432280-0001)(199646) $22.80 NEW IN STOCK |
| Heat Shield | 410366-0004 (197394)(431055-0001, 431055-0003, 410366-0003, 410366-0007) $19.50 NEW IN STOCK |
| Repair Kit | 709143-0001 (200423-0000, 707903-0002)(1100025761) $69.00 NEW IN STOCK |
| Turbine Housing | 441184-0004 (311820) |
| Compressor Cover | 443209-0127 (312392) |
| Turbine Housing AR | 1.34 |
| Gasket (turbine inlet) | 132040 (202873, 205396, 205396, 3500683, 210017-0000, 409038-0000, 1S4295, 9749)(1900000003) $14.21 |
| Gasket (turbine inlet) | 210239 (Stainless Steel) $22.00 |
| Gasket oil inlet | 129119 (201049, 9737, 1S6595, 210019-0000, 409266-0003, 3819900)(1900000035) $4.40 |
| Gasket (oil outlet) | 210060 (409267-0003, 409267-0002, 210060-0000, 51914, 148062, 311585, 2475013) $4.48 |
| NOTE | Complete replacement turbo only. Supersedes 466074-1. Hose Outlet |
| Manufacturer | Honeywell-Garrett |
1984- Volvo/Volvo-Penta F12/ N12/NL12 Truck with TD121F USA, TD121G Engine
