| Part Number | 3523646 |
| Previous versions | 186626, 186626R, 310183, 310183R, 3523647, 3802049, 4033263, 4033263H |
| OE number | 4663911, 4663912, 466395, 466466, 466730, 466876, 466877, 5001742, 500848556, 500848557, 847057, 847856, 847857, 848556, 9000848556, 9000848557 |
| Description | Volvo Penta, VCE Truck |
| CHRA | 3575016 (3524053, 4027384, 3524053H, 3575016H) $300.00 NEW IN STOCK, MADE IN USA |
| Turbo Model | H2A-8243AB/H16JA8, H2A |
| Engine | TD70G, TD70E, TD71GG, TD61GG, TD70, TD61FG |
| Engine Manufacturer | Volvo |
| KW | 155 |
| Angle α (compressor housing) | 360° |
| Angle β (turbine housing) | 360° |
| Bearing Housing | 3502500 (3520574, 3530591, 3530592)(Oil Cooled)(1152301450) $70.00 NEW IN STOCK |
| Turbine Wheel | 3519892 (3535359, 3522879)(Ind. 75.92 mm, Exd. 64. mm, Trm 10.41, 12 Blades, LH)(1152301436) $127.00 NEW IN STOCK |
| Comp. Wheel | 3599639 (Ind. 50. mm, Exd. 82. mm, Trm 5.94, 8+8 Blades) $45.92 NEW IN STOCK |
| Seal Plate | 3522801 $26.20 NEW IN STOCK |
| Heat shield Number | 3519302 (3527184)(1152301561) $14.00 NEW IN STOCK |
| Repair Kit | 4027309 (3545652, 3802007, 3802089, 3802147, 3908148, 3802149, 4027309)(1152301750) $74.00 NEW IN STOCK |
| Turbine Housing | 3523278 |
| Compressor Cover | 3522385 |
| Gasket (turbine inlet) | 409039-0000 (Inox Steel)(409039-0001, 210019, 2405022)(1900000006) $13.52 |
| Gasket (turbine outlet) | 210226 (2405066)(Stainless Steel) $29.00 |
| Gasket oil inlet | 210023 (210023-0000, 147837, 210021, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037) $4.48 |
| Gasket (oil outlet) | 210021 (148062, 311496, 3519807, 413671-0000, 409037-0000)(1900000027) $3.32 |
| Alternatives | 409840-0001, 409840-0002, 409840-0003, 409840-0004, 409840-0005, 409840-0006, 409840-0007, 186626 |
| Manufacturer | HOLSET |
1988-04 >Volvo Truck with TD70G, TD70E, TD71GG, TD61GG, TD70, TD61FG Engine
1988-04 Volvo Penta Truck with TD70G, TD70E, TD71GG, TD61GG, TD70, TD61FG Engine
