Part Number | 3796905 |
Previous versions | 4033627H, 3536614 |
OE number | OE52534 |
Year | 1991- |
Description | Various Marine Perkins Shrewsbury Seddon Stratos Diesel Eagle |
Manufacturer Part Number | 3536615 |
CHRA | 3575203 (1000020112) $380.00 NEW IN STOCK, MADE IN USA |
Turbo Model | HX50-E9861BU/S25B11, HX50 |
Engine Manufacturer | Perkins |
Engine | CV12TCA |
Fuel | Diesel |
Angle α (compressor housing) | 286.5° |
Angle β (turbine housing) | 180° |
Bearing Housing | 3533052 $86.00 NEW IN STOCK |
Turbine Wheel | 3534287 (Ind. 85.97 mm, Exd. 76.96 mm, 12 blades) $148.00 NEW IN STOCK |
Comp. Wheel | 3593629 (4041666)(Ind. 65.12 mm, Exd. 97.66 mm, 7+7 blades, Superback) $67.25 NEW IN STOCK |
Back plate | 3528096 $22.48 NEW IN STOCK |
Heat shield Number | 3529846 (3533038) $13.22 NEW IN STOCK |
Repair Kit | 3545627 (1153050750) $85.20 NEW IN STOCK |
Gasket (turbine inlet) | 310694 (407294-0001) $13.84 |
Gasket (turbine outlet) | 210226 (Stainless Steel) $29.00 |
Gasket oil inlet | 210023 (409036-0000, 210023-0000, 55739, 147837, 215234, 52231586500) $4.48 |
Gasket (oil outlet) | 210021 (409037-0000, 210021-0000, 311496, 413671-0000, 3519807) $4.48 |
Replaces | 3536615 |
Manufacturer | HOLSET |
1991- Perkins Various CV12TCA
