| Part Number | 743347-5001S |
| Previous Version | 743347-0001, 743347-1 |
| Description | Performance Performance Upgrade 250-400 HP 1.8L-3.0L (Ball Bearings) |
| CHRA | 446179-0031/446179-5031S Dual ball bearing, oil & water-cooled |
| Turbo Model | GT2871R |
| KW | 250/400 |
| Displacement | 1.8L/3.0L |
| Compressor Wheel | Ind Whl Dia (mm) 49.20/ Exd Whl Dia (mm) 71.00/ Trim 48/ A/R 0.60 |
| Turbine Wheel | Dia (mm) 53.90/ Trim 76/ A/R 0.86 |
| Turbine Housing | 430609-0231 (5-Bolt) |
| Compressor Cover | 446296-0019 |
| Actuator | 480009-0006 |
| Turbine Housing AR | 0.86 |
| Gasket (turbine inlet) | 210218 |
| Gasket Turbine outlet | 210649 |
| Fitting oil inlet | 431863-0006 |
| Gasket (oil outlet) | 210399 |
| NOTE | Bearing Type: Ball Cooling System Oil & Water, Cooled Waste gated Housing, internal Actuator Complete |
| NOTE | Turbine wheel cast from "Inconel" material for extreme applications |
| NOTE | Upgrade turbocharger for GT2860RS (PN 739548-1) 743347-1 features a high boost actuator adjustable down to 12 psi 743347-3 features a low boost actuator adjustable down to 6 psi |
| Manufacturer | Honeywell-Garrett |
Suitable for 1.8L to 3.0L Engines
Upgrade for 739548-0001
