| Part Number | 774595-5002S |
| Previous Version | 774595-0002, 774595-2, 774595-3, 774595-4 |
| Description | Performance Upgrade 425/850 HP 2.0L-7.0L (Ball Bearings)< |
| CHRA | 451888-0009/451888-0011/451888-5009S Dual ball bearing, oil & water-cooled |
| Turbo Model | GT4294R |
| KW | 425/850 |
| Displacement | 2.0L-7.0L |
| Compressor Wheel | Ind Wheel Dia (mm) 70.30/ Exd Wheel Dia (mm) 94.00/ Trim 56/ A/R 0.60 |
| Turbine Wheel | Dia. (mm) 82.00/ Trim 84/ A/R 1.15 |
| Turbine Housing | 757707-0010 Large Frame, V Band, Free Float |
| Compressor Cover | |
| Turbine Housing AR | 1.01 |
| Gasket (turbine inlet) | 407294-0001 |
| Gasket oil inlet | 210019 |
| Gasket (oil outlet) | 210060 |
| NOTE | Bearing Type: Ball Cooling System Oil & Water, Cooled Waste gated Housing, external |
| NOTE | Ported shroud compressor housing to increase surge resistance |
| NOTE | Free float, non-waste gated turbine Housings |
| Manufacturer | Honeywell-Garrett |
Suitable for 2.0L to 8.0L Engines
